Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Altus, Shimano -
Suspension Rigid -
Brakes Rim
Sizing
Recommended size guide.
18"
163cm - 175cm
20"
172cm - 185cm
22"
183cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 700c
Suspension Fork
hi-ten
Drivetrain
Rear Derailleur
SHIMANO Altus
Shift Levers
SHIMANO Revoshift (8)
Cassette
SHIMANO HG-31 11-34 (8)
Crank
LASCO 38 teeth 170 mm cranks
Chain
KMC 8.1
Pedals
WELLGO Non Slip alloy
Wheels
Front Hub
QUANDO 32 holes
Rear Hub
QUANDO 32 holes
Rims
aloy 32 holes
Spokes
steel 2.0 mm
Tires
CST Sensamo Speed 700 x 35c
Brakes
Brakes
PROMAX V
Cockpit
Stem
alloy
Handlebar
alloy 30 mm 610 mm
Grips
vinyl
Seat
Saddle
AUTHOR King Sofa
Seatpost
alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 18" | 20" | 22" |
|---|---|---|---|
| Front Center | 623 mm | 631 mm | 659 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 526 mm | 561 mm | 626 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 125 mm | 130 mm | 140 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1070 mm | 1078 mm | 1106 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 163 cm | 172 cm | 183 cm |
| Rider Max Height | 175 cm | 185 cm | 200 cm |
About this model
Voyage completes the Author Voyage model. Author released 3 bikes variations of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Commuter bikes
According to our calculations, the average cost of a Commuter bike that is reliable is 762$. However, you could also get a good Commuter bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Commuter bikes
Commuter bikes have an average weight of 14.29 kg (31.5 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Author Voyage it’s weighing 12.9 kg (28.44 lbs). At this weight, is considerably lighter than average. To sum up, it’s 10.78% lighter than the average weight of Commuter bikes.
Overview of components
Fork material
Voyage has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
When it comes to wheels, the Voyage bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Author Voyage has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
Sizes
This bike is available in 3 sizes. They vary from 163 cm – 200 cm (5.35 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
