Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Groupset microSHIFT Mezzo, microSHIFT M21 -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ADT Custom FormTech 6061 Alloy, Integrated Headtube, Replaceable dropouts
Suspension Fork
Suspension, Alloy Crown and Lowers, 80mm Travel
Drivetrain
Rear Derailleur
Micro Shift RD-M21L
Front Derailleur
Micro Shift FD-M20
Shift Levers
Micro Shift TS39 21 speed triggers
Cassette
Micro Shift CS-H071, 7-Speed, 12-28T Cassette
Crank
Prowheel Alloy 42/32/24T
Bottom Bracket
Cartridge
Chain
KMC HP6L
Pedals
Resin Platform with ball bearings
Wheels
Front Hub
Alloy, 32H QR Cassette Disc
Rear Hub
Alloy, 32H QR Cassette Disc
Rims
Lightweight Alloy 32H Double Wall Disc
Spokes
Stainless Steel
Tires
MTB 27.5 x 2.6
Brakes
Brakes
JAK Y-2 Hydraulic Disc, 160mm Rotors
Brake Levers
JAK Y-2 Hydraulic
Cockpit
Handlebar
Lightweight Alloy Riser, 15 Rise, 9Sweep, 680mm wide, 31.8mm
Grips
MTB Kraton soft comfort
Headset
Zoom Alloy ahead
Seat
Saddle
Zero Sport
Seatpost
Alloy 27.2 x 300mm, alloy QR
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Front Center | 617 mm | 628 mm | 631 mm | 652 mm | 677 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Top Tube Length | 530 mm | 552 mm | 565 mm | 585 mm | 610 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 330 mm | 380 mm | 430 mm | 480 mm | 520 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 90 mm | 90 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1062 mm | 1073 mm | 1076 mm | 1097 mm | 1122 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 680 mm | 705 mm | 747 mm | 779 mm | 806 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
