Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCR Air
-
Groupset Deore -
Suspension Hardtail -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch Powertube 500Wh Internal -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Alloy with Ultra Light butted tubing, tapered head tube, Powertube internal battery and internal cables
Suspension Fork
Suntour XCR34 Boost Air RLR, 1.5" Taper, 100 mm, rebound adjust, 15x110 mm axle, remote lockout
Drivetrain
Rear Derailleur
Shimano Deore 10sp Shadow Plus
Shift Levers
Shimano Deore 10sp
Cassette
Shimano M4100 10 speed 11-46T
Crank
FSA Gen 4 Bosch ISIS, 34T
Bottom Bracket
Bosch, press-fit
Chain
KMC E10 E-bike chain
Wheels
Front Hub
Shimano MT400 110x15 front, 148x12 rear 32H
Rear Hub
Shimano MT400 110x15 front, 148x12 rear 32H
Rims
Tubeless-Ready Double-wall Alloy 32H
Spokes
Stainless Steel
Tires
Kenda Booster Pro 27.5/29x2.6" 120tpi, folding, SCT (Tubeless Ready)
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 180 Centrelock Rotors
Brake Levers
Shimano MT201 hydraulic
Cockpit
Handlebar
Syncros FL 2.0 31.8mm, with 15mm rise, 9 deg sweep
Grips
Syncros Lock-on
Headset
Integrated Threadless 1 1/8th - 1.5"
Seat
Saddle
Syncros ER 2.5
Seatpost
Syncros Duncan Dropper 31.6mm with internal cable routing
Motor & Battery
Motor
Bosch G4 Performance Line CX
Battery
Bosch Powertube 500Wh Internal
Charger
Bosch Std 4A Charger
