Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork X-Fusion RC32
-
Groupset microSHIFT Advent X -
Suspension Hardtail -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch SmartSystem Powertube 500Wh Internal -
Drivetrain 1 × 10 -
Brakes Tektro Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Alloy with Ultra Lite butted tubing, tapered head tube, Powertube internal battery and internal cables
Suspension Fork
X-Fusion RC32 Boost Air, 1.5” Taper, 120mm, rebound, 15x110 axle, remote lockout
Drivetrain
Rear Derailleur
Microshift Advent X 10sp with Clutch
Shift Levers
Microshift Advent X 10sp Single-Click E-bike Trail Pro trigger
Cassette
Microshift E-cassette, 11-48T, 10sp
Crank
FSA Gen4 Bosch ISIS 34T Megatooth Narrow/Wide
Bottom Bracket
Bosch, press-fit
Chain
KMC E-bike chain
Wheels
Front Hub
Fr: Formula Boost Sealed Bearing 110x15 32H, Rr: Formula Boost Sealed Bearing 148x12 32H
Rear Hub
Fr: Formula Boost Sealed Bearing 110x15 32H, Rr: Formula Boost Sealed Bearing 148x12 32H
Rims
Alex DP30, Double-wall, eyeleted Alloy 32H, TL ready
Spokes
Stainless Steel with Brass Nipples
Tires
Kenda Nevegal Pro 29 x2.6 with FV tube, ATC, Tubeless Ready
Brakes
Brakes
Tektro M275 Hydraulic with 180mm rotors
Cockpit
Handlebar
Syncros Hixon 2.0 Butted Alloy, 31.8mm with 12mm rise, 9 deg sweep
Grips
Syncros Lock-on
Headset
Acros ZS56 eMTBN with block lock and internal cable routing
Seat
Saddle
Syncros ER 2.5
Seatpost
Sycros Duncan Dropper 31.6mm with internal cable routing
Motor & Battery
Motor
Bosch Gen 4 SmartSystem Performance Line CX
Battery
Bosch SmartSystem Powertube 500Wh Internal
Charger
Bosch SmartSystem 4A
