Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork Suntour XCR Air
-
Groupset Deore, FSA -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch SmartSystem Powertube 750Wh Internal -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Alloy with Ultra Lite butted tubing, tapered head tube, Powertube internal battery and internal cables
Suspension Fork
Suntour XCR34 Boost Air, RLR, 1.5" Taper, 120mm, rebound adjust, 15x110mm axle, remote lockout
Drivetrain
Rear Derailleur
Shimano Deore 11sp Shadow Plus
Shift Levers
Shimano Deore 11sp
Cassette
Shimano Deore Cassette, 11-speed 11-51T
Crank
FSA Gen 4 Bosch ISIS, 34T
Bottom Bracket
Bosch, press-fit
Chain
KMC E-bike chain
Wheels
Front Hub
Shimano MT400 110x15 front, 148x12 rear 32H
Rear Hub
Shimano MT400 110x15 front, 148x12 rear 32H
Rims
Alex EXR 30 Double-wall Alloy 32H
Spokes
Stainless Steel with Brass Nippl
Tires
Kenda Booster Pro 29 x2.4 with FV tube, Cap3, Tubeless Ready
Brakes
Brakes
Shimano MT420 Hydraulic Disc, 203 front/180mm rear Cetrelock Rotors
Brake Levers
Shimano MT401 Hydraulic
Cockpit
Handlebar
Syncros Hixon 2.0, 6 deg rise, 9 deg sweep
Grips
Syncros Lock-on
Headset
Acros ZS56 eMTBN with block lock and internal cable routing
Seat
Saddle
Syncros ER 2.5
Seatpost
Sycros Duncan Dropper 31.6mm with internal cable routing
Motor & Battery
Motor
Bosch SmartSystem Performance Line CX
Battery
Bosch SmartSystem Powertube 750Wh Internal
Charger
Bosch SmartSystem
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.62 mm | 1.61 mm | 1.63 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 682 mm | 694 mm | 704 mm | 717 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 101 mm | 100 mm | 102 mm | 101 mm |
| Stack | 646 mm | 655 mm | 665 mm | 683 mm |
| Reach | 398 mm | 405 mm | 413 mm | 418 mm |
| Top Tube Length | 583 mm | 593 mm | 603 mm | 613 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm | 520 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm | 160 mm |
| Chainstay Length | 503 mm | 503 mm | 503 mm | 503 mm |
| Wheelbase | 1178 mm | 1190 mm | 1200 mm | 1213 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 783 mm | 794 mm | 815 mm | 847 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Competitor-E2 is part of the Avanti E Competitor E2 model. Avanti launched 1 e-bike of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail e-bikes
According to our calculations, the average cost of a Trail e-bike that is reliable is 3365$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Competitor-E2 components
Fork
The fork installed on this bike is the Suntour XCR Air model. The travel on this model is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Avanti Competitor-E2 2023, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Competitor-E2 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Avanti Competitor-E2 includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
