Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork Suntour XCR Air
-
Groupset Deore -
Suspension Hardtail -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch SmartSystem Powertube 750Wh Internal -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Alloy with Ultra Lite butted tubing, tapered head tube, Powertube internal battery and internal cables
Suspension Fork
Suntour XCR34 Boost Air, RLR, 1.5" Taper, 120mm, rebound adjust, 15x110mm axle, remote lockout
Drivetrain
Rear Derailleur
Shimano Deore 11sp Shadow Plus
Shift Levers
Shimano Deore 11sp
Cassette
Shimano Deore Cassette, 11-speed 11-51T
Crank
FSA Gen 4 Bosch ISIS, 34T
Bottom Bracket
Bosch, press-fit
Chain
KMC E-bike chain
Wheels
Front Hub
Shimano MT400 110x15 front, 148x12 rear 32H
Rear Hub
Shimano MT400 110x15 front, 148x12 rear 32H
Rims
Alex EXR 30 Double-wall Alloy 32H
Spokes
Stainless Steel with Brass Nippl
Tires
Kenda Booster Pro 29 x2.4 with FV tube, Cap3, Tubeless Ready
Brakes
Brakes
Shimano MT420 Hydraulic Disc, 203 front/180mm rear Cetrelock Rotors
Brake Levers
Shimano MT401 Hydraulic
Cockpit
Handlebar
Syncros Hixon 2.0, 6 deg rise, 9 deg sweep
Grips
Syncros Lock-on
Headset
Acros ZS56 eMTBN with block lock and internal cable routing
Seat
Saddle
Syncros ER 2.5
Seatpost
Sycros Duncan Dropper 31.6mm with internal cable routing
Motor & Battery
Motor
Bosch SmartSystem Performance Line CX
Battery
Bosch SmartSystem Powertube 750Wh Internal
Charger
Bosch SmartSystem
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.628 mm | 1.622 mm | 1.615 mm | 1.639 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 682 mm | 694 mm | 704 mm | 717 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 101 mm | 100 mm | 102 mm | 101 mm |
| Stack | 643 mm | 652 mm | 662 mm | 680 mm |
| Reach | 395 mm | 402 mm | 410 mm | 415 mm |
| Top Tube Length | 580 mm | 590 mm | 600 mm | 610 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm | 520 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm | 160 mm |
| Chainstay Length | 500 mm | 500 mm | 500 mm | 500 mm |
| Wheelbase | 1175 mm | 1187 mm | 1197 mm | 1210 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 780 mm | 791 mm | 812 mm | 844 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
