Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 65mm -
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ADT 6061 Formtech Alloy, Disc Brake Design
Suspension Fork
HL 187 Suspension fork, 65mm Travel,
Drivetrain
Rear Derailleur
Shimano Altus
Front Derailleur
Shimano TY510
Shift Levers
Shimano EF500 21-Speed
Cassette
Shimano HG200 Cassette, 12-32T 7 Speed
Crank
Shimano TY301 48/38/28T
Bottom Bracket
Cartridge
Chain
KMC Z-7
Pedals
Nylon platform with ball bearings
Wheels
Front Hub
Front: Shimano TX505 Alloy, Rear TY505 Alloy Centrelock Cassette 32H
Rear Hub
Front: Shimano TX505 Alloy, Rear TY505 Alloy Centrelock Cassette 32H
Rims
Alex TD26 Double-wall Alloy 36H
Spokes
Stainless Steel
Tires
Kenda Piedmont 700 x 40c AV valve
Brakes
Brakes
Tektro Aries Mechanical Disc, 160mm rotors
Brake Levers
Shimano EF500
Cockpit
Handlebar
Alloy Riser, 31.8mm, 15mm rise, 5 deg sweep, 680mm
Grips
Zero Comfort
Headset
Integrated Aheadset 1-1/8"
Seat
Saddle
Zero Comfort
Seatpost
Alloy 27.2mm Micro Adjust with Suspension, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.585 mm | 1.577 mm | 1.572 mm | 1.567 mm |
| Front Center | 622 mm | 633 mm | 658 mm | 664 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 80 mm | 91 mm | 80 mm | 91 mm |
| Stack | 599 mm | 618 mm | 632 mm | 647 mm |
| Reach | 378 mm | 392 mm | 402 mm | 413 mm |
| Top Tube Length | 550 mm | 570 mm | 590 mm | 605 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 350 mm | 425 mm | 480 mm | 535 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 130 mm | 150 mm | 165 mm | 180 mm |
| Chainstay Length | 455 mm | 455 mm | 445 mm | 455 mm |
| Wheelbase | 1069 mm | 1080 mm | 1095 mm | 1111 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 683 mm | 731 mm | 766 mm | 803 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
