Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 65mm -
Fork Zoom
-
Groupset microSHIFT Acolyte, Shimano -
Suspension Hardtail -
Motor Shimano 250W 40Nm mid-drive -
Battery Shimano E6010 418Wh -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ADT 6061 Formtech Alloy, Shimano STEPS mount, low step
Suspension Fork
HL Zoom 187D, 65mm travel, Mechanical Lock-out w/firm spring
Drivetrain
Rear Derailleur
Microshift Acolyte 8sp with Clutch
Shift Levers
Microshift Acolyte 8sp Xpress trigge
Cassette
Microshift Acolyte cassette, 12-42T, 8sp
Crank
Shimano E5010 with CR050 Alloy, 44T chainwheel
Bottom Bracket
STEPS, press-fit
Chain
KMC Z8 8sp E-bike chain
Pedals
Nylon platform with ball bearings
Wheels
Front Hub
Joytech alloy cassette disc 36H
Rear Hub
Joytech alloy cassette disc 36H
Rims
Alex TD26 Double-wall Alloy, 36H
Spokes
Stainless Steel
Tires
Kenda Small Block 8 29 x 1.75 with AV tube W/K-Sheild
Brakes
Brakes
Tektro M275 Hydraulic
Brake Levers
Tektro M275 Hydraulic
Cockpit
Handlebar
Alloy comfort 25.4, 33deg rear sweep
Grips
Zero Comfort
Headset
Semi Integrated Aheadset
Seat
Saddle
Zero Zymo Comfort with high density foam
Seatpost
Alloy 27.2mm Micro Adjust with Suspension
Motor & Battery
Motor
Shimano E5000
Battery
Shimano E6010 418Wh
Charger
Shimano E6002
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM/MD | MD/LG |
|---|---|---|
| Stack Reach Ratio | 1.79 mm | 1.74 mm |
| Front Center | 641 mm | 651 mm |
| Rake | 38 mm | 38 mm |
| Trail | 93 mm | 87 mm |
| Stack | 648 mm | 661 mm |
| Reach | 362 mm | 379 mm |
| Top Tube Length | 551 mm | 571 mm |
| Seat Tube Angle | 74 ° | 74 ° |
| Seat Tube Length | 425 mm | 480 mm |
| Head Tube Angle | 69 ° | 70 ° |
| Head Tube Length | 160 mm | 170 mm |
| Chainstay Length | 477 mm | 477 mm |
| Wheelbase | 1109 mm | 1119 mm |
| Bottom Bracket Drop | 70 mm | 70 mm |
| Standover Height | 688 mm | 679 mm |
| Wheels | 700 | 700 |
About this model
Discovery-E Low completes the Avanti E Discovery E model. 3 e-bikes variations carry this model name so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Comfort e-bikes average price
According to our math, the average price for a trustworthy Comfort e-bike is 1957$. However, this doesn’t mean that if you spend less money on a Comfort e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Discovery-E Low components
Fork
This e-bike has the Zoom fork installed. The fork’s travel is 65mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When it comes to wheels, the Discovery-E Low e-bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Discovery-E Low has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
