Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 65mm -
Fork Zoom
-
Groupset microSHIFT Acolyte -
Suspension Hardtail -
Motor Shimano 250W 40Nm mid-drive -
Battery Shimano E6010 418Wh -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ADT 6061 Formtech Alloy, Shimano STEPS mount, low step
Suspension Fork
HL Zoom 187D, 65mm travel, Mechanical Lock-out w/firm spring
Drivetrain
Rear Derailleur
Microshift Acolyte 8sp with Clutch
Shift Levers
Microshift Acolyte 8sp Xpress trigge
Cassette
Microshift Acolyte cassette, 12-42T, 8sp
Crank
Shimano E5010 with CR050 Alloy, 44T chainwheel
Bottom Bracket
STEPS, press-fit
Chain
KMC Z8 8sp E-bike chain
Pedals
Nylon platform with ball bearings
Wheels
Front Hub
Joytech alloy cassette disc 36H
Rear Hub
Joytech alloy cassette disc 36H
Rims
Alex TD26 Double-wall Alloy, 36H
Spokes
Stainless Steel
Tires
Kenda Small Block 8 29 x 1.75 with AV tube W/K-Sheild
Brakes
Brakes
Tektro M275 Hydraulic
Brake Levers
Tektro M275 Hydraulic
Cockpit
Handlebar
Alloy comfort 25.4, 33deg rear sweep
Grips
Zero Comfort
Headset
Semi Integrated Aheadset
Seat
Saddle
Zero Zymo Comfort with high density foam
Seatpost
Alloy 27.2mm Micro Adjust with Suspension
Motor & Battery
Motor
Shimano E5000
Battery
Shimano E6010 418Wh
Charger
Shimano E6002
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM/MD | MD/LG |
|---|---|---|
| Stack Reach Ratio | 1.771 mm | 1.727 mm |
| Front Center | 641 mm | 651 mm |
| Rake | 38 mm | 38 mm |
| Trail | 93 mm | 87 mm |
| Stack | 657 mm | 670 mm |
| Reach | 371 mm | 388 mm |
| Top Tube Length | 560 mm | 580 mm |
| Seat Tube Angle | 74 ° | 74 ° |
| Seat Tube Length | 425 mm | 480 mm |
| Head Tube Angle | 69 ° | 70 ° |
| Head Tube Length | 160 mm | 170 mm |
| Chainstay Length | 486 mm | 486 mm |
| Wheelbase | 1118 mm | 1128 mm |
| Bottom Bracket Drop | 70 mm | 70 mm |
| Standover Height | 697 mm | 688 mm |
| Wheels | 700 | 700 |
