Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Nexus -
Suspension Rigid -
Motor Shimano 250W 40Nm mid-drive -
Battery Shimano E8014 418Wh -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Lightweight alloy folding frame with semi-integrated battery and mid drive Shimano motor - KlickFix headtube port and ABUS lock port included
Suspension Fork
Lightweight full alloy
Drivetrain
Shift Levers
Shimano Nexus 7sp RapidFire Plus
Cassette
Shimano 18T
Crank
Shimano E5010 with CR050 Alloy, 44T chainwheel
Chain
KMC E-bike chain
Pedals
Wellgo folding
Wheels
Front Hub
Front: Shimano TX505 Centrelock 36H, Rear: Shimano Nexus 7sp Disc
Rear Hub
Front: Shimano TX505 Centrelock 36H, Rear: Shimano Nexus 7sp Disc
Rims
Alex DP21 Double-wall Alloy 36H
Spokes
Stainless Steel
Tires
Kenda Konversion 20x1.95 with Iron Cap Belt & AV tube
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 180 front/160mm rear Centrelock Rotors
Brake Levers
Shimano MT200 Hydraulic
Cockpit
Handlebar
Alloy Riser, 15mm degree bend
Grips
Ergonomic comfort
Headset
Semi Integrated Aheadset
Seat
Saddle
Selle Royal Lookin comfort with RoyalGel padding
Seatpost
Alloy with micro-adjust
Motor & Battery
Motor
Shimano eSTEPS E5000
Battery
Shimano E8014 418Wh
Charger
Shimano E6002
Fit data
