Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Travel Rear 80mm -
Fork Suntour MOBIE
-
Groupset Deore -
Suspension Full -
Motor Bosch 600W 63Nm mid-drive -
Battery Bosch Powertube 500Wh Internal -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Ultralight tubing, 80mm travel, cartridge bearing pivots, tapered headtube, PowerTube internal battery
Suspension Fork
Suntour Mobie 25 LOR Air, Taper, 100 mm, 15x100 mm axle, remote lockout
Drivetrain
Rear Derailleur
Shimano Deore 10sp Shadow Plus
Shift Levers
Shimano Deore 10sp
Cassette
Shimano Deore Cassette, 10-speed 11-42T
Crank
FSA Gen 3 Bosch ISIS, 38T
Bottom Bracket
Bosch, press-fit
Chain
KMC E10 E-bike chain
Pedals
VP retro with alloy body and rubber gripper
Wheels
Front Hub
Front: Formula centrelock alloy 100x15 32H, Rear: Formula Alloy Centrelock Cassette 148x12mm thru axle
Rear Hub
Front: Formula centrelock alloy 100x15 32H, Rear: Formula Alloy Centrelock Cassette 148x12mm thru axle
Rims
Alex GX26P Gravel rims, double wall
Spokes
Sapim Stainless Steel
Tires
Kenda Sabre 29 x 2.2 with AV tube.
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 180 Centrelock Rotors
Brake Levers
Shimano MT201 hydraulic
Cockpit
Handlebar
Alloy riser bar, 15 deg sweep
Grips
Dual density Ergo
Headset
Integrated Threadless 1 1/8th - 1.5"
Seat
Saddle
Selle Royal Lookin comfort with RoyalGel padding
Seatpost
Syncros Duncan Dropper 31.6mm with internal cable routing
Motor & Battery
Motor
Bosch G3 Performance Line
Battery
Bosch Powertube 500Wh Internal
Charger
Bosch Std 4A Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.485 mm | 1.483 mm | 1.481 mm |
| Front Center | 677 mm | 694 mm | 709 mm | 725 mm |
| Rake | 44 mm | 44 mm | 44 mm | 45 mm |
| Trail | 84 mm | 84 mm | 84 mm | 82 mm |
| Stack | 620 mm | 634 mm | 648 mm | 662 mm |
| Reach | 416 mm | 427 mm | 437 mm | 447 mm |
| Top Tube Length | 590 mm | 605 mm | 620 mm | 637 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 445 mm | 480 mm | 525 mm | 555 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 125 mm | 140 mm | 155 mm | 170 mm |
| Chainstay Length | 480 mm | 480 mm | 480 mm | 480 mm |
| Wheelbase | 1153 mm | 1170 mm | 1185 mm | 1201 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 736 mm | 736 mm | 755 mm | 781 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
