Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tourney, Altus -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ADT 6061 Formtech Alloy, Disc Brake Design, smooth weld
Suspension Fork
Alloy disc brake 1-1/8" Steerer
Drivetrain
Rear Derailleur
Shimano Altus
Front Derailleur
Shimano TX510
Shift Levers
Shimano EF505 21-Speed
Cassette
Shimano HG200-7 12-28T 7-Speed
Crank
Shimano TY301 48/38/28T
Bottom Bracket
Cartridge
Chain
KMC Z7
Pedals
Nylon platform with ball bearings
Wheels
Front Hub
Front: Shimano TX505, Rear: Shimano TY505 Centrelock Cassette 32H
Rear Hub
Front: Shimano TX505, Rear: Shimano TY505 Centrelock Cassette 32H
Rims
Weinmann QR17 Double-wall Alloy 32H
Spokes
Stainless Steel
Tires
Kenda Kwick Roller 700 x 35c with AV tubes
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 160mm Rotors
Brake Levers
Shimano
Cockpit
Handlebar
Alloy 31.8 with 9deg back sweep and 12mm rise, 620mm
Grips
Zero Strike Dual Compound
Headset
Integrated Aheadset 1-1/8"
Seat
Saddle
Zero Sport
Seatpost
Alloy Micro Adjust 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.448 mm | 1.476 mm | 1.507 mm | 1.496 mm |
| Front Center | 617 mm | 632 mm | 651 mm | 677 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 69 mm | 69 mm | 72 mm | 66 mm |
| Stack | 566 mm | 589 mm | 618 mm | 636 mm |
| Reach | 391 mm | 399 mm | 410 mm | 425 mm |
| Top Tube Length | 560 mm | 575 mm | 595 mm | 615 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm | 540 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 130 mm | 155 mm | 185 mm | 205 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1047 mm | 1063 mm | 1082 mm | 1108 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 709 mm | 740 mm | 772 mm | 803 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
