Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ultra Lite Butted Alloy, Gravel Geometry, 142x12mm Thru axle, Disc, dropper compatible
Suspension Fork
Carbon Gravel with 1.5"-1 1/8" Steerer, 100x12mm Thru Axle, Flat Mount Disc Brake
Drivetrain
Rear Derailleur
Shimano GRX RD-RX812
Front Derailleur
Shimano GRX FD-RX810-F
Shift Levers
Shimano GRX ST-RX600-22-Speed
Cassette
Shimano GRX CS-HG700-11 11-34T 11-Speed
Crank
Shimano GRX RX-600-11 with 46/30T
Bottom Bracket
Shimano Hollowtech II
Chain
CN-HG601-11
Wheels
Front Hub
Shimano RS470 32H Alloy Centrelock Cassette, w/12x100 and 12x142 t/axle, w/Syncros SwitchBolt axle
Rear Hub
Shimano RS470 32H Alloy Centrelock Cassette, w/12x100 and 12x142 t/axle, w/Syncros SwitchBolt axle
Rims
Alex GX26, double-wall alloy, TL-ready, hooked 23mm (inner), 32H
Spokes
Double butted Stainless
Tires
Kenda Alluvium Pro 700x40c, 120tpi, DTC compound, tubeless ready
Brakes
Brakes
Shimano GRX BR-RX400 Hydraulic Disc, 160mm Rotors
Brake Levers
Shimano GRX RX600 Hydraulic Disc
Cockpit
Handlebar
Syncros Creston 2.0 Alloy 10deg Flare 31.8mm, 53=461mm, 54.5-56=481mm, 57.5-59=501mm (measured at drops)
Grips
Super-grip, Shockproof
Headset
Acros Integrated Aheadset 1-1/8-1.5", internal cable routing
Seat
Saddle
Syncros Belcarra 2.5
Seatpost
Syncros 3.0 Alloy 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM/MD | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.474 mm | 1.485 mm | 1.495 mm | 1.505 mm | 1.514 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 616 mm | 633 mm | 649 mm | 665 mm | 682 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 74 mm | 74 mm | 74 mm | 75 mm | 75 mm |
| Stack | 560 mm | 579 mm | 598 mm | 617 mm | 636 mm |
| Reach | 380 mm | 390 mm | 400 mm | 410 mm | 420 mm |
| Top Tube Length | 530 mm | 545 mm | 560 mm | 575 mm | 590 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 485 mm | 510 mm | 535 mm | 560 mm | 585 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1041 mm | 1058 mm | 1075 mm | 1091 mm | 1108 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 774 mm | 796 mm | 817 mm | 839 mm | 861 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
