Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox 35 Silver
-
Groupset SX Eagle -
Suspension Full -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch Powertube 500Wh Internal -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Ultralight tubing, 150mm travel, cartridge bearing pivots, 1.5" tapered headtube, PowerTube internal battery
Suspension Fork
Rockshox 35 Silver TK Solo Air, 160mm, air spring, 1.5" taper, rebound adjust, lock-out, Boost 110 15mm axle - S=27.5, M/L/XL=29er
Rear Shock
Rockshox Delux Select R, Debon Air, rebound adjust
Drivetrain
Rear Derailleur
SRAM SX Eagle
Shift Levers
SRAM SX Eagle, 12sp
Cassette
SRAM PG-1210 Cassette, 11-50T, 12 speed
Crank
FSA Gen 4 Bosch ISIS, 34T SRAM X-Sync chainwheel
Bottom Bracket
Bosch, press-fit
Chain
SRAM SX Eagle
Wheels
Front Hub
Front: Shimano MT400 110x15 32H, Rear: Shimano MT400 148x12 32H
Rear Hub
Front: Shimano MT400 110x15 32H, Rear: Shimano MT400 148x12 32H
Rims
Tubeless-Ready Double-wall Alloy 32H
Spokes
Stainless Steel
Tires
Kenda Regolith 29 x2.6" (Fr & Rr on M/L/XL frame size), 27.5x2.6" (Fr & Rr on S frame size) 120tpi, folding, SCT (Tubeless Ready)
Brakes
Brakes
Shimano M420 hydraulic, 203mm rotors
Brake Levers
Shimano M401 hydraulic
Cockpit
Handlebar
Syncros Hixon 2.0, 31.8mm, with 12mm rise, 9 deg sweep
Grips
Syncros Lock-on
Headset
Integrated Threadless 1 1/8th - 1.5" (with extra lower geometry adjust cup for 27.5+ )
Seat
Saddle
Syncros ER 2.5
Seatpost
Syncros Duncan Dropper 31.6mm with internal cable routing
Motor & Battery
Motor
Bosch G4 Performance Line CX
Battery
Bosch Powertube 500Wh Internal
Charger
Bosch Std 4A Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.512 mm | 1.427 mm | 1.372 mm | 1.316 mm |
| Bottom Bracket Height | 330 mm | 349 mm | 349 mm | 349 mm |
| Front Center | 754 mm | 779 mm | 808 mm | 844 mm |
| Rake | 44 mm | 51 mm | 51 mm | 51 mm |
| Trail | 106 mm | 115 mm | 116 mm | 116 mm |
| Stack | 635 mm | 635 mm | 645 mm | 658 mm |
| Reach | 420 mm | 445 mm | 470 mm | 500 mm |
| Top Tube Length | 583 mm | 608 mm | 636 mm | 671 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 404 mm | 440 mm | 472 mm | 517 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm | 145 mm |
| Chainstay Length | 462 mm | 462 mm | 462 mm | 462 mm |
| Wheelbase | 1215 mm | 1240 mm | 1269 mm | 1305 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 766 mm | 790 mm | 810 mm | 841 mm |
| Wheels | 27" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
