Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 130mm -
Travel Rear 120mm -
Fork Marzocchi Bomber Z2
-
Groupset microSHIFT XCD -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Ultralight Butted tubing, 120mm travel, cartridge bearing pivots, 1.5” tapered headtube, PF92 BB, 12 x 148m
Suspension Fork
Marzocchi Z2 Bomber Air w/RAIL damper, 15x110mm axle, 1.5” taper, 130mm travel
Rear Shock
X-Fusion 02 Pro R Air, with rebound adjust
Drivetrain
Rear Derailleur
Microshift XCD 11sp with Clutch
Shift Levers
Microshift XCD 11sp Trail trigger w/Sealed Bearing
Cassette
Microshift cassette, 11-46T, 11sp
Crank
ProWheel MPX Boost, forged alloy crank, w/32T narrow/wide alloy (replaceable) chainring)
Bottom Bracket
Pressfit
Chain
KMC X11
Wheels
Front Hub
Fr: Formula Boost Sealed Bearing 110x15 32H, Rr: Formula Boost Sealed Bearing 148x12 32H
Rear Hub
Fr: Formula Boost Sealed Bearing 110x15 32H, Rr: Formula Boost Sealed Bearing 148x12 32H
Rims
Alex DP-27 Double-wall Alloy with eyelet 32H, Tubeless Ready
Spokes
Stainless steel
Tires
Kenda Regolith, 29 x 2.4” Folding, 60tpi
Brakes
Brakes
SRAM DB8 4-Piston hydraulic, 180mm 6-bolt rotors
Brake Levers
SRAM DB8 hydraulic
Cockpit
Handlebar
Syncros Alloy 31.8mm, with low rise, 9 deg sweep
Grips
Syncros Pro Lock-on
Headset
Integrated Threadless Syncros OE Pressfit/ Tapered 1.5”-1 1/8”
Seat
Saddle
Syncros Belcarra 2.5
Seatpost
Syncros Duncan Dropper 31.6mm with internal cable routing
