Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Groupset Nexus -
Suspension Rigid -
Motor Bosch 600W 63Nm mid-drive -
Battery Bosch Powertube 500Wh Internal -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Alloy with Ultra Light butted tubing, tapered head tube, Powertube internal battery and internal cables
Suspension Fork
AL-6061 Alloy rigid, tapered, Boost 110 15mm axle
Drivetrain
Shift Levers
Shimano Nexus 7sp RapidFire Plus
Cassette
Shimano 18T
Crank
FSA Gen 3 Bosch, 38T
Bottom Bracket
Bosch, press-fit
Chain
KMC
Wheels
Front Hub
Front: Shimano MT400 110x15 32H, Rear: Shimano Nexus 7sp Disc 36H
Rear Hub
Front: Shimano MT400 110x15 32H, Rear: Shimano Nexus 7sp Disc 36H
Rims
Alex DP 27 Double-wall Alloy
Spokes
Stainless Steel
Tires
Kenda Small Block 8 29 x 1.9 with FV tube
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 180 front/160mm rear Cetrelock Rotors
Brake Levers
Shimano MT200 hydraulic
Cockpit
Handlebar
Syncros FL 2.0 31.8mm, riser bar, 9 deg sweep
Grips
VP retro with alloy body and rubber gripper
Headset
Integrated Threadless 1 1/8th - 1.5"
Seat
Saddle
Syncros ER 2.5
Seatpost
Alloy Micro Adjust 31.6mm
Motor & Battery
Motor
Bosch G3 Performance Line
Battery
Bosch Powertube 500Wh Internal
Charger
Bosch Std 4A Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.501 mm | 1.539 mm | 1.595 mm | 1.634 mm |
| Front Center | 658 mm | 664 mm | 668 mm | 673 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 74 mm | 71 mm | 71 mm | 67 mm |
| Stack | 605.8 mm | 626.8 mm | 645.7 mm | 666.8 mm |
| Reach | 403.7 mm | 407.2 mm | 404.9 mm | 408.1 mm |
| Top Tube Length | 594.7 mm | 604.8 mm | 614.7 mm | 624.8 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72 ° | 72 ° |
| Seat Tube Length | 455 mm | 495 mm | 535 mm | 575 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 71 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 473 mm | 473 mm | 473 mm | 473 mm |
| Wheelbase | 1124 mm | 1130 mm | 1134 mm | 1139 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 777 mm | 810 mm | 842 mm | 873 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
