Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour MOBIE
-
Groupset Deore -
Suspension Hardtail -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch Powertube 625Wh Internal -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Ultra Light butted, super-low-step frame
Suspension Fork
Suntour Mobie 25, RLR DS, Tapered Steerer, Remote Lockout, 100 mm, 15x100 mm axle
Drivetrain
Rear Derailleur
Shimano Deore 11sp Shadow Plus
Shift Levers
Shimano Deore 11sp
Cassette
Shimano Deore Cassette, 11-speed 11-51T
Crank
Shimano MT200 Hydraulic Disc, 180 front/160 rear Centrelock Rotors
Chain
KMC E11 E-bike chain
Pedals
VP retro with alloy body and rubber gripper
Wheels
Front Hub
Front: Shimano MT400 100x15 32H, Rear: Shimano M3050 Centrelock Cassette 32H
Rear Hub
Front: Shimano MT400 100x15 32H, Rear: Shimano M3050 Centrelock Cassette 32H
Rims
Alex DP 27 Double-wall Alloy 32H
Spokes
Sapim Stainless Steel
Tires
Kenda Small Block 8 29 x 2.1 with K Shield, reflective logos & AV tube
Brakes
Brakes
Shimano MT201 Hydraulic Disc, 180 front/160mm rear Centrelock Rotors
Brake Levers
Shimano MT200 hydraulic
Cockpit
Handlebar
Alloy riser bar, 15 deg sweep
Grips
Dual density Ergo
Headset
Acros, A-Headset, integrated, 1.5", with integrated cable routing
Seat
Saddle
Selle Royal Lookin comfort with RoyalGel padding
Seatpost
Syncros Duncan Dropper 31.6mm with internal cable routing
Motor & Battery
Motor
Bosch G4 Performance Line CX
Battery
Bosch Powertube 625Wh Internal
Charger
Bosch Std 4A Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM/MD | MD/LG |
|---|---|---|
| Stack Reach Ratio | 1.605 mm | 1.639 mm |
| Front Center | 655 mm | 665 mm |
| Rake | 42 mm | 41 mm |
| Trail | 86 mm | 87 mm |
| Stack | 634 mm | 654 mm |
| Reach | 395 mm | 399 mm |
| Top Tube Length | 595 mm | 605 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 500 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° |
| Head Tube Length | 160 mm | 180 mm |
| Chainstay Length | 499 mm | 499 mm |
| Wheelbase | 1145 mm | 1155 mm |
| Bottom Bracket Drop | 70 mm | 70 mm |
| Standover Height | 450 mm | 450 mm |
| Wheels | 700 | 700 |
