Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCT
-
Groupset Altus -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ADT 6061 Formtech Alloy, Women's Geometry, Replaceable Hanger, internal brake cable
Suspension Fork
SR Suntour XCT30, 100mm Travel, Lock-out
Drivetrain
Rear Derailleur
Shimano Altus 9sp Shadow
Front Derailleur
Shimano Altus
Shift Levers
Shimano Altus 18sp
Cassette
Shimano HG200 Cassette, 11-36T, 9sp
Crank
Shimano MT101 36/22T
Bottom Bracket
Cartridge
Chain
KMC Z-9
Pedals
Nylon platform with ball bearings
Wheels
Front Hub
Shimano TX505 Alloy Centrelock Cassette 32H
Rear Hub
Shimano TX505 Alloy Centrelock Cassette 32H
Rims
Weinmann XRD28 Double-wall Alloy 32H
Spokes
Stainless Steel
Tires
Kenda Aptor 27.5x2.20 MTB tyre with AV tube
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 160mm Rotors
Brake Levers
Shimano MT200 Hydraulic
Cockpit
Handlebar
Alloy 31.8 with 9deg back sweep and 12mm rise, XS-S=660mm, M=680mm
Grips
Zero Strike Dual Compound
Headset
Semi-Integrated Aheadset 1-1/8"
Seat
Saddle
Zero Women's Sport Comfort
Seatpost
Zero Alloy 27.2mm, 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Front Center | 628 mm | 644 mm | 659 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Top Tube Length | 555 mm | 570 mm | 590 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 360 mm | 380 mm | 420 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° |
| Head Tube Length | 110 mm | 115 mm | 125 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1055 mm | 1072 mm | 1087 mm |
| Bottom Bracket Drop | 55 mm | 52 mm | 52 mm |
| Standover Height | 683 mm | 694 mm | 718 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
