Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Fork Suntour XCR -
Groupset Alivio -
Suspension Hardtail -
Motor Bosch 600W 63Nm mid-drive -
Battery Bosch Powertube 500Wh Internal -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Alloy with Ultra Light butted tubing, tapered head tube, Powertube internal battery and internal cables
Suspension Fork
Suntour XCR32 ATB, 100 mm, fixed rebound and lockout QR
Drivetrain
Rear Derailleur
Shimano Alivio Shadow 9 speed
Shift Levers
Shimano Alivio 9sp
Cassette
Sunrace CSM90 9 speed 11-36T
Crank
FSA Gen 3 Bosch, 32T
Bottom Bracket
Bosch, press-fit
Chain
KMC E9 E-bike chain
Wheels
Front Hub
Front: Alex DP 27 Double-wall Alloy 32H, Rear: Formula Alloy Centrelock Cassette 148x12mm thru axle
Rear Hub
Front: Alex DP 27 Double-wall Alloy 32H, Rear: Formula Alloy Centrelock Cassette 148x12mm thru axle
Rims
Alex DP 27 Double-wall Alloy 32H
Spokes
Stainless Steel
Tires
Kenda Slant Six 29x2.35"
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 180 Centrelock Rotors
Brake Levers
Shimano MT200 hydraulic
Cockpit
Handlebar
Low riser bar
Grips
Syncros Lock-On
Headset
Integrated Threadless 1 1/8th - 1.5"
Seat
Saddle
Syncros ER 2.5
Seatpost
Syncros Duncan Dropper 31.6mm with internal cable routing
Motor & Battery
Motor
Bosch G3 Performance Line
Battery
Bosch Powertube 500Wh Internal
Charger
Bosch Std 2A Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.578 mm | 1.566 mm | 1.523 mm | 1.518 mm |
| Bottom Bracket Height | 286 mm | 305 mm | 305 mm | 305 mm |
| Front Center | 651 mm | 659 mm | 674 mm | 675 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 85 mm | 92 mm | 92 mm | 81 mm |
| Stack | 620 mm | 625 mm | 629 mm | 645 mm |
| Reach | 393 mm | 399 mm | 413 mm | 425 mm |
| Top Tube Length | 582 mm | 590 mm | 599 mm | 616 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 420 mm | 445 mm | 480 mm | 525 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 71 ° |
| Head Tube Length | 120 mm | 125 mm | 130 mm | 140 mm |
| Chainstay Length | 480 mm | 480 mm | 480 mm | 480 mm |
| Wheelbase | 1122 mm | 1130 mm | 1145 mm | 1146 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 740 mm | 759 mm | 765 mm | 796 mm |
| Wheels | 27" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
