Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 50mm -
Fork Suntour XCT
-
Groupset microSHIFT Mezzo -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ADT 6061 FormTech Alloy, forged dropouts, integrated head tube, replaceable hanger
Suspension Fork
SR XCT Jr, Alloy Crown and Lower Legs, 50mmTravel, custom colour and decal
Drivetrain
Rear Derailleur
Micro Shift RD-M36L
Shift Levers
Micro Shift TS39 8 speed trigger
Cassette
Micro Shift CS-H081, 8-Speed, 12-32T Cassette
Crank
Jr Alloy 28T with chain guide
Bottom Bracket
Cartridge
Chain
KMC Z-7
Pedals
VP youth platform with ball bearings
Wheels
Front Hub
KT Alloy, 32H QR Cassette Disc
Rear Hub
KT Alloy, 32H QR Cassette Disc
Rims
Lightweight Alloy 32H
Spokes
Stainless Steel
Tires
Kenda Slant Six 24 x 2.6", AV tubes
Brakes
Brakes
JAK Y-2 Hydraulic Disc, 160mm Rotors
Brake Levers
JAK Y-2 Hydraulic
Cockpit
Handlebar
Lightweight Oversized Alloy riser 620mm with 9deg sweep
Grips
MTB Soft Kraton comfort
Headset
1 1/8th Ahead Internal semi cartridge
Seat
Saddle
Zero Junior Sport
Seatpost
Alloy Microadjust 27.2mm x 300mm, alloy QR
Fit data
Geometry
