Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ADT 6061 Butted Formtech Ultralight Alloy Disc brake, internal cable routing, rack/fender compatible
Suspension Fork
SR NEX DS with 63mm Travel
Drivetrain
Rear Derailleur
Shimano Altus
Front Derailleur
Shimano TX510
Shift Levers
Shimano Altus 21-Speed
Cassette
Shimano HG200-7 12-28T 7-Speed
Crank
Shimano TY301 48/38/28T
Bottom Bracket
Cartridge
Chain
KMC Z7
Pedals
Nylon platform with ball bearings
Wheels
Front Hub
Front: Shimano TX505 Alloy, Rear: TY505 Alloy Centrelock Cassette 32H
Rear Hub
Front: Shimano TX505 Alloy, Rear: TY505 Alloy Centrelock Cassette 32H
Rims
Alex TD26 Double-wall Alloy 32H
Spokes
Stainless Steel
Tires
Kenda Piedmont 700 x 40c with K-Shield and AV valve
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 160mm Rotors
Brake Levers
Shimano
Cockpit
Handlebar
Alloy 31.8 with 9deg back sweep and 12mm rise, S=640mm, M=660mm, L-XL=680mm
Grips
Zero Strike Dual Compound
Headset
Integrated Aheadset 1-1/8"
Seat
Saddle
Zero Zealth Sport
Seatpost
Alloy Micro Adjust 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.552 mm | 1.555 mm | 1.543 mm | 1.555 mm |
| Front Center | 632 mm | 647 mm | 662 mm | 672 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 81 mm | 80 mm | 82 mm | 83 mm |
| Stack | 610 mm | 625 mm | 639 mm | 653 mm |
| Reach | 393 mm | 402 mm | 414 mm | 420 mm |
| Top Tube Length | 575 mm | 595 mm | 610 mm | 620 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 410 mm | 450 mm | 495 mm | 545 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 115 mm | 130 mm | 145 mm | 160 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1064 mm | 1079 mm | 1094 mm | 1104 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 753 mm | 782 mm | 815 mm | 847 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
