Basso Diamante Shimano Ultegra 8170 Di2 2024
2024 Road
Estimate price |
8,491$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Ultegra, Ultegra Di2 -
Suspension Rigid -
Drivetrain Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
Shimano Ultegra 8170 Di2
Cassette
Shimano Ultegra 8170 Di2 11-34T
Crank
Shimano Ultegra 8170 Di2 50-34T
Wheels
Rims
Microtech RE38
Brakes
Brakes
Rim
Seat
Seatpost
Diamante 2023 -15 mm seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 48cm | 51cm | 53cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.392 mm | 1.391 mm | 1.443 mm | 1.452 mm | 1.51 mm | 1.563 mm | 1.618 mm |
| Stack | 521.7 mm | 521.8 mm | 546.2 mm | 558.8 mm | 584.3 mm | 608 mm | 632.2 mm |
| Reach | 374.9 mm | 375.2 mm | 378.6 mm | 384.8 mm | 386.9 mm | 389 mm | 390.7 mm |
| Top Tube Length | 505 mm | 515 mm | 525 mm | 545 mm | 560 mm | 575 mm | 590 mm |
| Seat Tube Angle | 76 ° | 75 ° | 75 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 530 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 71.3 ° | 71.4 ° | 71.6 ° | 71.9 ° | 73.1 ° | 73.1 ° | 73.6 ° |
| Head Tube Length | 101 mm | 101 mm | 126 mm | 138 mm | 155 mm | 180 mm | 203 mm |
| Chainstay Length | 400 mm | 400 mm | 400 mm | 400 mm | 402 mm | 402 mm | 406 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
