Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Apex -
Suspension Rigid -
Motor Polini 250W 75Nm mid-drive -
Battery The engine is the Polini EP3 + Evo, with more than 75Nm of torque and 250W of power. The integrated 500 Wh Polini battery offers 5 customizable assistance levels and up to 220 km of assistance. A compact, powerful and durable propulsion system, compatible with the bottle battery extender (which adds an additional 250Wh of assistance) and technological accessories. -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Cassette
SRAM Apex 1x11 11-42T
Crank
SRAM Apex 1x11 44T
Wheels
Rims
Microtech MX 25
Tires
Continental Terra Trail 700 x 40 mm Tires
Brakes
Brakes
Mechanical Disc
Cockpit
Stem
Tera Stem
Handlebar
Microtech XL Gravel Handlebar
Seat
Saddle
Selle Italia X3 Boost Flow Saddle
Motor & Battery
Motor
The engine is the Polini EP3 + Evo, with more than 75Nm of torque and 250W of power. The integrated 500 Wh Polini battery offers 5 customizable assistance levels and up to 220 km of assistance. A compact, powerful and durable propulsion system, compatible with the bottle battery extender (which adds an additional 250Wh of assistance) and technological accessories.
Battery
The engine is the Polini EP3 + Evo, with more than 75Nm of torque and 250W of power. The integrated 500 Wh Polini battery offers 5 customizable assistance levels and up to 220 km of assistance. A compact, powerful and durable propulsion system, compatible with the bottle battery extender (which adds an additional 250Wh of assistance) and technological accessories.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.621 mm | 1.577 mm | 1.526 mm | 1.418 mm |
| Stack | 581.6 mm | 581.6 mm | 600.4 mm | 600.4 mm |
| Reach | 358.7 mm | 368.7 mm | 393.5 mm | 423.5 mm |
| Top Tube Length | 520 mm | 530 mm | 560 mm | 590 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 540 mm | 570 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 165 mm | 165 mm | 185 mm | 185 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
