Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Steel -
Suspension Rigid
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|---|
| Top Tube Length | 510 mm | 520 mm | 535 mm | 545 mm | 560 mm | 570 mm | 580 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71.5 ° | 72.5 ° | 72.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 90 mm | 104 mm | 120 mm | 136 mm | 155 mm | 174 mm | 194 mm |
| Chainstay Length | 406 mm | 407 mm | 409 mm | 411 mm | 411 mm | 413 mm | 415 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
