Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Apex -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Cassette
SRAM Apex 1x11 11-42T
Crank
SRAM Apex 1x11 44T
Wheels
Rims
Microtech MX 25
Brakes
Brakes
Hydraulic Disc
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.578 mm | 1.593 mm | 1.579 mm | 1.535 mm |
| Stack | 549 mm | 580 mm | 603 mm | 617 mm |
| Reach | 348 mm | 364 mm | 382 mm | 402 mm |
| Top Tube Length | 500 mm | 530 mm | 560 mm | 590 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 430 mm | 490 mm | 540 mm | 570 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 71 ° | 71 ° |
| Head Tube Length | 130 mm | 160 mm | 180 mm | 195 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
