Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Nexus -
Suspension Rigid -
Motor Bosch 250W 65Nm mid-drive -
Battery Bosch Powerpack 400Wh/500Wh Lithium-Ion -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum Alloy with Front Tray Mounts
Suspension Fork
Oversized CRMO Steel
Drivetrain
Shift Levers
Shimano Nexus Revo 5-Speed
Cassette
Shimano Nexus, Single Sprocket 24T
Chain
Taya e-OCTO-5S, 110 Links
Chain Guide
Semi Enclosed, Aluminum
Pedals
One Piece Aluminum, Non Slip TPE Threads
Wheels
Front Hub
Shimano HBM4050
Rear Hub
Shimano Nexus 5-Speed
Rims
Aluminum, Double Wall, 36H
Spokes
Stainless 14G
Tires
Balloon Tires 26? x 2.35?, Puncture Resistant, 60 TPI
Brakes
Brakes
Shimano Hydraulic Disk, Rotor 160mm
Brake Levers
Shimano
Cockpit
Stem
Aluminum, Threadless, Extension 60mm
Handlebar
Aluminum, Width 640mm, Rise 70mm
Grips
Benno Ergo Profile, Lock-On
Headset
FSA Intergrated
Seat
Saddle
Benno Low Profile Comfort with Elastomer Springs
Seatpost
Aluminum, Diameter 27.2mm, Length 350mm
Motor & Battery
Motor
Bosch Performance 250W, 65Nm, GEN 3
Battery
Bosch Powerpack 400Wh/500Wh Lithium-Ion
Remote
Bosch Purion Display
Charger
Bosch Compact 2A (400Wh Battery), 4A (500Wh Battery)
