Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Sora, Acera -
Suspension Rigid -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch Powerpack 400Wh/545Wh Lithium-Ion -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum Alloy with Front Tray Mounts
Suspension Fork
Oversized 4130 CRMO Steel
Drivetrain
Rear Derailleur
Shimano Sora
Shift Levers
Shimano Acera
Cassette
Shimano CS 9-Speed, 11~32T
Chain
Taya e-NOVE-91, 148 Links
Pedals
One Piece Aluminum
Wheels
Front Hub
KT Aluminum 135mm
Rear Hub
KT Aluminum 170mm
Rims
Aluminum, Double Wall, 36H
Spokes
Stainless 14G
Tires
Benno RemiDemi All Road Tire 20? x 3.6?, Puncture Resistant, 60 TPI
Brakes
Brakes
Magura MT Thirty Disc 2 Piston, Rotor 180mm
Brake Levers
Magura MT Thirty
Cockpit
Stem
Aluminum, Threadless, Extension 60mm
Handlebar
Aluminum, Width 675mm, Rise 126mm
Grips
Benno Ergo Profile, Lock-On
Headset
FSA Intergrated
Seat
Saddle
Benno Low Profile Comfort with Elastomer Springs
Seatpost
Aluminum, Diameter 30.9, Length 350mm
Motor & Battery
Motor
Bosch Performance Smart System 250W, 75Nm, GEN 3
Battery
Bosch Powerpack 400Wh/545Wh Lithium-Ion
Remote
LED Remote
Charger
Bosch Compact 2A (400Wh Battery), 4A (545Wh Battery)
