Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Travel Front 160mm -
Fork Suntour MOBIE
-
Groupset XT -
Suspension Hardtail -
Motor Bosch 85Nm hub-drive -
Battery Bosch PowerTube 750 horizontal -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bergstrom eTrekking Bosch, Modular Battery Downtube, Bosch G4 mount, Smart-Route cable routing on the steering head, 34.9mm seat post, Racktime RTA fender & rack mount, 2 bottle cage mounts.
Suspension Fork
Suntour Mobie25 700 RLO suspension fork, tapered steerer, 32mm stanchions, Postmount 160, steel spring, 15QLC axle 110x15mm, eyelets for fender mounting, lockout and tension adjustment
Drivetrain
Shift Levers
Shimano SLX SL-M8130
Cassette
Shimano CS-M8130 11spd LinkGlide
Crank
Miranda Delta 170mm ISIS
Bottom Bracket
Bosch, press-fit
Chain
Shimano CN-LG500 LinkGlide 11spd
Chain Guide
optionally retrofittable
Pedals
VP-831P grip tape pedals
Wheels
Rims
Front: Shimano 100×15 hub with Rodi RYOT 28 rim, DT Competition spokes, Rear: Shimano 135×5 hub with Rodi RYOT 28 rim, DT Competition spokes
Tires
Schwalbe G-One Bite 28?x2.0? (50-622) Classic Skin
Brakes
Brakes
SRAM DB8 4-piston 180/180mm
Cockpit
Stem
Satoir Viper 0 ICR Stem 60mm/31.8mm
Handlebar
Satori Horizon Bow Di2 handlebar 780×31.8mm, 7mm rise
Seat
Saddle
Ergon SM10 black
Seatpost
Satori Xopic Suspension 34.9x350mm
Motor & Battery
Motor
Bosch CX BES3 85Nm 25km/h
Battery
Bosch PowerTube 750 horizontal
Charger
36V 4A Charger, 230V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.52 mm | 1.49 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Stack | 660 mm | 660 mm | 660 mm |
| Reach | 422 mm | 434 mm | 442 mm |
| Top Tube Length | 611 mm | 623 mm | 631 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 470 mm | 500 mm | 540 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 170 mm | 170 mm | 170 mm |
| Chainstay Length | 483 mm | 483 mm | 483 mm |
| Wheelbase | 1167 mm | 1179 mm | 1187 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
GTV 750 is part of the Bergstrom E Gtv model. There are 4 e-bikes that carry this model name.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Commuter e-bikes average price
According to our math, the average price for a trustworthy Commuter e-bike is 2569$. However, even though the average price of a Commuter e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
GTV 750 components
Fork
The Suntour MOBIE is included from the factory. It has a travel distance of 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork on this e-bike is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the e-bike.
Wheels
The wheels on GTV 750 are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Bergstrom GTV 750 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Bergstrom GTV 750 e-bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
