Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Rear 28mm -
Groupset Apex -
Suspension Full -
Drivetrain 1 × 12 -
Brakes SRAM Apex Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 166cm
SM
164cm - 176cm
MD
174cm - 186cm
LG
184cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Allroad Carbon, Geometry BGC with 28mm travel SOFTEX Suspension System, Full carbon HM2X, Triple monocoque, BB86 bottom bracket, Full internal cable system ICS2, Headset semi integrated OH2S 1-1/2"- 1-1/2", Flat Mount 140mm, 700x44c maximum tyre, Dropper post ready, Thru axle 12x142mm, UDH standard, weight: 1060gr
Suspension Fork
Allroad EVO, full carbon, internal cable system ICS2, 1-1/8" - 1-1/2" Tapered, Flat Mount Standard max. 160mm disc, 700x44c maximum tyre, Flip-chip adust 45-51mm fork rake, 405mm axle to crown, Thru axle 12x100mm, weight: 500gr
Drivetrain
Cassette
SRAM XPLR PG1231, 11-44T
Crank
SRAM APEX D1 AL DUB WIDE Crankset, 42T, 170-172,5-175
Bottom Bracket
SRAM DUB BB86 Press Fit Wide
Chain
SRAM APEX D1 12S 114 LINKS
Wheels
Rims
Vision Trimax 30, Aluminum rim, TLR, inner width 23mm, rim height 30mm, Center Lock, weight: 1680gr.
Tires
Pirelli Cintauro GRAVEL H, 700x40C, TLR, 120 TPI, TechWALL Gravel, SpeedGrip Compound
Brakes
Brakes
SRAM APEX AXS D1 Hydraulic Shift-Brake System
Cockpit
Handlebar
Avanforce AF1 GRAVEL, UD Carbon, Ø31,8, Drop: 125mm, Reach 80mm, width: 400, 420, 440mm, weight: 300gr
Seat
Saddle
Fizik Vento Argo X5, Steel rails 7x7mm, length 265 mm, width 140 mm, weight 240g
Seatpost
Avanforce Tibia, Softex Seat post, UD Carbon, 0 offset, Ø27,2, length: 300,350,420mm, total weight: 195gr
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.418 mm | 1.425 mm | 1.442 mm | 1.447 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 593 mm | 607 mm | 620 mm | 630 mm | 642 mm |
| Rake | 44 mm | 44 mm | 46 mm | 45 mm | 45 mm |
| Trail | 82 mm | 78.7 mm | 75.3 mm | 72 mm | 68.7 mm |
| Stack | 535 mm | 550 mm | 567 mm | 587 mm | 605 mm |
| Reach | 374 mm | 388 mm | 398 mm | 407 mm | 418 mm |
| Seat Tube Angle | 75.1 ° | 74.8 ° | 74.5 ° | 74.2 ° | 73.9 ° |
| Seat Tube Length | 460 mm | 484 mm | 508 mm | 532 mm | 556 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 98 mm | 113 mm | 129 mm | 146 mm | 164 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1000 mm | 1015 mm | 1028 mm | 1038 mm | 1050 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 164 cm | 174 cm | 184 cm | 191 cm |
| Rider Max Height | 166 cm | 176 cm | 186 cm | 193 cm | cm |
