Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Shimano 105 Hydraulic Disc
Sizing
Recommended size guide.
51cm
155cm - 165cm
53cm
165cm - 175cm
55cm
175cm - 185cm
57cm
185cm - 192cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Belador Blade 6 full carbon fork, internal cable system ICS2, 1-1/8" - 1-1/2" Tapered head tube compatible, Flat Mount System brake, 700x34c maximum tyre, Thru axle 12x100mm
Drivetrain
Rear Derailleur
SHIMANO 105, FD-R7100, 12s
Cassette
CS-R7100, 11-34T
Crank
SHIMANO 105, FC-R7100 Crankset, 50x34T, 170-172,5-175mm
Bottom Bracket
BBT47 Token
Chain
CN-M6100, 118 Links
Wheels
Rims
Vision Team 30, Aluminum rim, TLR, inner width 23mm, rim height 30mm, Center Lock
Brakes
Brakes
SHIMANO 105 BR-R7120, Hydraulic Disc
Cockpit
Handlebar
Avanforce Airone, Integrated Road Carbon Handlebar, Full internal cable system ICS2, sizes: 380x90, 400x100, 400x110, 420x110, 420x120
Seat
Saddle
Fizik Vento Argo X5, Steel rails 7x7mm, length 265 mm, width: 140 mm
Seatpost
Belador 6 SP, UD Carbon, Offset: 0, 20mm offset, ISP technology
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 5 | 51cm | 53cm | 55cm | 57cm | 59cm |
|---|---|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
