Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 100mm -
Fork RockShox Judy
-
Groupset X1 -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes SRAM Level Hydraulic Disc
Sizing
Recommended size guide.
XS
150cm - 165cm
SM
160cm - 176cm
MD
174cm - 185cm
LG
180cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bravo 5 EVO, XCO Racing Geometry BGC, Full carbon HMR2X, Triple monocoque, resin Matrix Nanotech CNT, BB92 botton bracket, Active Stay, Asymmetric, Full internal cable system ICS2, Headset semi integrated OH2S 1-1/2", Post Mount brake PMS, 29x2.35" max. tyre.
Suspension Fork
RockShox Judy TK, Damper Type Turnkey, Remote Lockout 2 Position, 15x110mm Maxle Stealth, Tapered steerer, Rake 51mm, 30mm straight wall aluminium, Diffusion Black, 100mm travel
Drivetrain
Cassette
SRAM XG 1275 Eagle, 10-52T, weight 452gr
Crank
SRAM X1 1000 DUB Eagle Boost 34T 170-175mm
Bottom Bracket
Bottom Bracket PF92 DUB MTB
Chain
SRAM SX Eagle A1, 118 links
Wheels
Rims
Mavic Crossride 29", 15x110, Boost 12x148mm, TLR, XDR Rear Hub, Center Lock, internal width: 30mm, weight: 2075gr
Tires
Vittoria Barzo, 29x2,25", Rigid Bead, weight: 800gr
Brakes
Brakes
SRAM Level Black 2 Piston
Cockpit
Handlebar
Avanforce AF3, Aluminum 6061, Ø31,8mm, wide 740mm, weight 330gr
Seat
Saddle
Selle Royal 2058HRN, Steel rails, length: 285mm, width: 145mm, weight: 315gr
Seatpost
Avanforce AF3, Aluminum 6061, 0 offset, Ø27,2 x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.463 mm | 1.383 mm | 1.332 mm |
| Bottom Bracket Height | 308 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 662 mm | 675 mm | 704 mm | 726 mm |
| Rake | 49 mm | 49 mm | 49 mm | 52 mm |
| Trail | 97.7 mm | 94.2 mm | 94.2 mm | 90.7 mm |
| Stack | 602.4 mm | 604.7 mm | 609.2 mm | 616.2 mm |
| Reach | 396.2 mm | 413.3 mm | 440.4 mm | 462.5 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 425 mm | 470 mm | 520 mm |
| Head Tube Angle | 68.6 ° | 69.1 ° | 69.1 ° | 69.6 ° |
| Head Tube Length | 93 mm | 95 mm | 100 mm | 105 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1080 mm | 1094 mm | 1123 mm | 1145 mm |
| Bottom Bracket Drop | 66 mm | 64 mm | 64 mm | 64 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 160 cm | 174 cm | 180 cm |
| Rider Max Height | 165 cm | 176 cm | 185 cm | 198 cm |
