Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Travel Front 100mm -
Fork RockShox Recon Silver RL
-
Groupset X1 -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes SRAM Level Hydraulic Disc
Sizing
Recommended size guide.
XS
150cm - 165cm
SM
160cm - 176cm
MD
174cm - 185cm
LG
180cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
RockShox RECON RL, Damper Motion Control, Remote Lockout 2 Position, 15x110mm Maxle Stealth, Tapered steerer, Rake 51, 32 mm straight wall aluminium, Diffusion Black, 100mm travel
Drivetrain
Cassette
CS PG1210 Eagle, 11-50T
Crank
SRAM X1 1000, DUB Eagle, 34T 170-175mm
Bottom Bracket
BB92 DUB PF
Chain
SRAM SX Eagle A1, 118 Links
Wheels
Rims
FULCRUM RED ZONE 700 29", Alloy Material, 15x110, Boost 12x148mm, TLR, HG11 Rear Hub, Center Lock, internal width 23mm
Brakes
Brakes
SRAM Level Black, 2 Piston
Cockpit
Handlebar
Avanforce AF3, Aluminum 6061, Ø31,8mm, width: 740mm
Seat
Saddle
Selle Royal 2058HRN, Steel rails, length: 285mm, width: 145mm
Seatpost
Avanforce AF3, Aluminum 6061, 0 offset, Ø27,2, length: 350, 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.509 mm | 1.419 mm | 1.393 mm | 1.372 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 311 mm | 311 mm |
| Front Center | 687 mm | 718 mm | 734 mm | 752 mm |
| Rake | 49 mm | 48 mm | 47 mm | 49 mm |
| Trail | 110 mm | 106 mm | 103 mm | 99 mm |
| Stack | 599 mm | 610 mm | 624 mm | 638 mm |
| Reach | 397 mm | 430 mm | 448 mm | 465 mm |
| Seat Tube Angle | 75.1 ° | 75.1 ° | 74.4 ° | 74.1 ° |
| Seat Tube Length | 380 mm | 431 mm | 470 mm | 521 mm |
| Head Tube Angle | 66.5 ° | 67 ° | 67.5 ° | 68 ° |
| Head Tube Length | 85 mm | 95 mm | 107 mm | 120 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1099 mm | 1130 mm | 1147 mm | 1165 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 160 cm | 174 cm | 180 cm |
| Rider Max Height | 165 cm | 176 cm | 185 cm | 198 cm |
