Berria BRAVO HPR ELITE NX 2024
2024 E-bike
Estimate price |
3,210$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork RockShox 35 Gold RL
-
Groupset NX Eagle -
Suspension Hardtail -
Motor Bafang 250W 60Nm mid-drive -
Battery PORTAPOWER 720Wh 36V 20Ah, Cells SAMSUNG INR21700-50E, 3960g -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 176cm
MD
174cm - 190cm
LG
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-Bravo HPR, 3BS 6061 Hydroformed and aluminum parts with Technology PCP Precision Casting Process, Full internal cable system ICS2, Headset integrated OH2S 1-1/2" - 1-1.8", Post mount 180mm, 29x2.35" maximum tyre, Thru axle Boost 12x148mm, UDH Standard, weight: 2700gr
Suspension Fork
RockShox 35 GOLD RL, Motion Control, 15x110mm Maxle Stealth, Tapered steerer, Rake 44mm, 35mm straight wall steel, Fast Black, 120mm travel, weight: 2277gr
Drivetrain
Rear Derailleur
SRAM NX Eagle, Aluminum cage, 12 Speed
Cassette
SRAM PG 1210 Eagle, 11-50T
Crank
Bafang Aluminum Alloy Cranks, 165-170mm, 34T
Bottom Bracket
BSA, 73mm, threaded
Chain
SRAM SX Eagle A1, 118 links
Wheels
Rims
Mavic E-Crossride 29", 15x110, Boost 12x148mm, TLR, HG11 Rear Hub, 6 Bolts, internal width: 30mm, weight: 2225gr
Tires
Vittoria Barzo 29x2,35", Tubeless ready, Graphene 2.0, 120 TPI, weight: 820gr
Brakes
Brakes
SRAM DB8 Black 4 Piston
Cockpit
Handlebar
Avanforce AF2 MTB, Aluminum 6061, Ø31,8mm, width 780mm, Backsweep 6°, Upsweep 5°, Rise 20mm, weight: 330gr
Seat
Saddle
Essax Era, Steel rails, length: 250mm, width: 145mm, weight: 280gr
Seatpost
TRANZX JD-YSPJL Aluminum 7075-T6, 0 offset, Ø31,6, 120mm travel, weight: 590gr
Motor & Battery
Motor
BAFANG M-SERIES 510, 250W - 60Nm, Peak Power and Torque: 500W - 95 Nm, Q factor 177mm, weight: 3370gr
Battery
PORTAPOWER 720Wh 36V 20Ah, Cells SAMSUNG INR21700-50E, 3960g
Charger
Porta Power charger 220-240V 3A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.551 mm | 1.479 mm | 1.401 mm |
| Bottom Bracket Height | 306 mm | 306 mm | 306 mm |
| Front Center | 718 mm | 728 mm | 758 mm |
| Rake | 50 mm | 52 mm | 52 mm |
| Trail | 102 mm | 102 mm | 102 mm |
| Stack | 639 mm | 645 mm | 650 |
| Reach | 412 mm | 436 mm | 464 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° |
| Seat Tube Length | 410 mm | 445 mm | 500 mm |
| Head Tube Angle | 66.5 ° | 68 ° | 68 ° |
| Head Tube Length | 115 mm | 115 mm | 120 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1162 mm | 1172 mm | 1202 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 174 cm | 185 cm |
| Rider Max Height | 176 cm | 190 cm | 200 cm |
