Berria BRAVO PRO S1000 AXS 2024
2024 Mountain
Estimate price |
3,954$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 110mm -
Travel Rear 28mm -
Fork RockShox SID
-
Groupset SRAM -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
150cm - 165cm
SM
160cm - 176cm
MD
174cm - 185cm
LG
180cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bravo 6, XCO WC Racing Geometry BGC with 28mm travel SOFTEX Suspension System, Full carbon HM2X, Triple monocoque, BB92 Bottom bracket, Full internal cable system ICS2, Integrated headset OH2S 1-1/2", Post Mount 160mm, 29x2.40" max. tyre, BOOST Thru axle 12x148mm, UDH standard, weight 1150gr (without hardware)
Suspension Fork
RockShox SID SL Base, Damper Rush RL, Remote Lockout 3 Position, 15x110 Maxle Stealth, Tapered steerer, Spring Debon Air, Rake 44mm, 32mm tapered wall aluminum, Diffusion Black, 110mm travel, weight: 1493gr
Drivetrain
Cassette
SRAM XS 1275 Eagle, T-TYPE, 10-52T
Crank
SRAM S1000 T-TYPE, 34T, QF: 174mm, 170-175mm, CL 55mm
Bottom Bracket
Bottom Bracket PF92 DUB WIDE MTB
Chain
SRAM GX T-TYPE Flattop, 118 links
Wheels
Rims
DT Swiss X1900 Spline 29", 15x110, Boost 12x148mm, TLR, XDR Rear Hub, Center Lock, internal width: 25mm, weight: 1844gr
Tires
Vittoria Barzo 29x2,25", Tubeless Ready, Graphene 2.0, 60 TPI, weight: 660gr
Brakes
Brakes
SRAM DB8 Black 4 Piston
Cockpit
Handlebar
Avanforce AF3, Aluminum 6061, Ø31,8mm, wide 740mm, weight 330gr
Seat
Saddle
Fizik Terra Aidon X5, Steel rails, length: 255mm, width: 145mm, weight: 262gr
Seatpost
Avanforce AF3, Aluminum 6061, 0 offset, Ø27,2 x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.509 mm | 1.419 mm | 1.393 mm | 1.372 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 311 mm | 311 mm |
| Front Center | 687 mm | 718 mm | 734 mm | 752 mm |
| Rake | 49 mm | 48 mm | 47 mm | 49 mm |
| Trail | 110 mm | 106 mm | 103 mm | 99 mm |
| Stack | 599 mm | 610 mm | 624 mm | 638 mm |
| Reach | 397 mm | 430 mm | 448 mm | 465 mm |
| Seat Tube Angle | 75.1 ° | 75.1 ° | 74.4 ° | 74.1 ° |
| Seat Tube Length | 380 mm | 431 mm | 470 mm | 521 mm |
| Head Tube Angle | 66.5 ° | 67 ° | 67.5 ° | 68 ° |
| Head Tube Length | 85 mm | 95 mm | 107 mm | 120 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1099 mm | 1130 mm | 1147 mm | 1165 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 160 cm | 174 cm | 180 cm |
| Rider Max Height | 165 cm | 176 cm | 185 cm | 198 cm |
