Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Travel Rear 28mm -
Suspension Full
Sizing
Recommended size guide.
XS
155cm - 166cm
SM
164cm - 176cm
MD
174cm - 186cm
LG
184cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Allroad Carbon, Geometry BGC with 28mm travel SOFTEX Suspension System, Full carbon HM2X, Triple monocoque, BB86 bottom bracket, Full internal cable system ICS2, Headset semi integrated OH2S 1-1/2"- 1-1/2", Flat Mount 140mm, 700x44c maximum tyre, Ø27,2 Dropper post ready, Thru axle 12x142mm, UDH standard, weight: 1060gr
Suspension Fork
Allroad EVO, full carbon, internal cable system ICS2, 1-1/8" - 1-1/2" Tapered, Flat Mount Standard max. 160mm disc, 700x44c maximum tyre, Flip-chip adust 45-51mm fork rake, 405mm axle to crown, Thru axle 12x100mm, weight: 500gr
Drivetrain
Bottom Bracket
BB86/BB92, press-fit
Cockpit
Handlebar
Avanforce Airone GR, lntegrated Gravel Carbon Handlebar, Full internal cable system ICS2, sizes 405x80 - 425x90/100/110 - 445x120, weight: 340gr
Seat
Seatpost
Avanforce Tibia, Softex Seat post, UD Carbon, 0 offset, Ø27,2, length: 300,350,420mm, total weight: 195gr
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.443 mm | 1.483 mm | 1.463 mm | 1.482 mm | 1.496 mm |
| Bottom Bracket Height | 272 mm | 272 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 603 mm | 614 mm | 619 mm | 630 mm | 648 mm |
| Rake | 56 mm | 56 mm | 55 mm | 55 mm | 56 mm |
| Trail | 82 mm | 78.7 mm | 75.3 mm | 72 mm | 68.7 mm |
| Stack | 535.9 mm | 561.5 mm | 566.2 mm | 587 mm | 614 mm |
| Reach | 371.4 mm | 378.7 mm | 387.1 mm | 396.1 mm | 410.3 mm |
| Seat Tube Angle | 74 ° | 73.75 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 460 mm | 484 mm | 508 mm | 532 mm | 556 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 100 mm | 125 mm | 130 mm | 150 mm | 177 mm |
| Chainstay Length | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm |
| Wheelbase | 1006 mm | 1018 mm | 1023 mm | 1035 mm | 1053 mm |
| Bottom Bracket Drop | 77 mm | 77 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 164 cm | 174 cm | 184 cm | 191 cm |
| Rider Max Height | 166 cm | 176 cm | 186 cm | 193 cm | cm |
