Berria MAKO PRO S 1000-SID 2024
2024 Mountain
Estimate price |
5,350$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 120mm -
Travel Rear 113mm -
Fork RockShox SID
-
Groupset SRAM -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 171cm
MD
169cm - 185cm
LG
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Mako 4, XCO Geometry BGC, 113mm travel with integrated IN-LINK suspension, Full carbon HM2X, monocoque, bearings full ball ISB VMAX, BB92 bottom bracket, full internal cable system ICS2, Integrated headset OH2S 1-1/2", Post Mount 160mm, 29x2.40" maximum tyre, BOOST Thru axle 12x148, UDH standard, weight: 1795gr (without hardware)
Suspension Fork
RockShox SID BSE, Damper Charger RL, Remote Lockout 3 Position, 15x110 Maxle Stealth, Tapered steerer, Spring Debon Air, Rake 44mm, 35mm tapered wall aluminum, Diffusion Black, 120mm travel, weight: 1646gr
Drivetrain
Cassette
SRAM XS 1275 Eagle, T-TYPE, 10-52T
Crank
SRAM S1000 T-TYPE, 34T, QF: 174mm, 170-175mm, CL 55mm
Bottom Bracket
Bottom Bracket PF92 DUB WIDE MTB
Chain
SRAM GX T-TYPE Flattop, 118 links
Wheels
Rims
DT Swiss X1900 Spline 29", 15x110, Boost 12x148mm, TLR, XDR Rear Hub, Center Lock, internal width: 25mm, weight: 1844gr
Tires
Vittoria Barzo 29x2,25", Tubeless Ready, Graphene 2.0, 60 TPI, weight: 660gr
Brakes
Brakes
Shimano Deore XT BL-M8100
Cockpit
Handlebar
Avanforce AF3, Aluminum 6061, Ø31,8mm, width 740mm, weight 330gr
Seat
Saddle
Fizik Vento Argo X5, Steel rails 7x7mm, length 265 mm, width 140 mm, weight 240g
Seatpost
Crank Brothers HIGHLINE 3 Dropper post, Aluminum 7075-T6, 0 offset, Ø31,6, 125mm travel, weight: 545gr
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.356 mm | 1.314 mm | 1.266 mm |
| Bottom Bracket Height | 327 mm | 327 mm | 327 mm |
| Front Center | 717 mm | 739 mm | 765 mm |
| Rake | 46 mm | 46 mm | 46 mm |
| Trail | 112 mm | 108 mm | 104 mm |
| Stack | 590 mm | 602 mm | 614 mm |
| Reach | 435 mm | 458 mm | 485 mm |
| Seat Tube Angle | 76.2 ° | 76 ° | 75.8 ° |
| Seat Tube Length | 400 mm | 445 mm | 490 mm |
| Head Tube Angle | 67 ° | 67.5 ° | 68 ° |
| Head Tube Length | 85 mm | 95 mm | 105 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1143 mm | 1165 mm | 1191 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 47 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 169 cm | 180 cm |
| Rider Max Height | 171 cm | 185 cm | 195 cm |
