Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 110mm -
Travel Rear 113mm -
Fork Fox Performance Float 34
-
Groupset Shimano -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Shimano XT Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 171cm
MD
169cm - 185cm
LG
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Mako 4, XCO Geometry BGC, 113mm travel with integrated IN-LINK suspension, Full carbon HM2X, monocoque, bearings full ball ISB VMAX, BB92 bottom bracket, full internal cable system ICS2, Integrated headset OH2S 1-1/2", Post Mount 160mm, 29x2.40" maximum tyre, BOOST Thru axle 12x148, UDH standard, weight: 1795gr (without hardware)
Suspension Fork
FOX 34 SC Float Performance Air Grip, Remote Lockout 3 Position, 15x110mm Kabolt axle, Rake 44mm, Tapered steerer, Reb. Adj. 110mm travel, weight: 1570gr
Drivetrain
Cassette
Shimano SLX CS-M7100-12, 10-51T
Crank
Shimano FC-MT510-1, 34T, 170-175mm
Bottom Bracket
Bottom Bracket PF92 SH MTB
Chain
Shimano CN-M6100, 118 links
Wheels
Rims
Mavic Crossride 29", 15x110, Boost 12x148mm, TLR, MS12 Rear Hub, Center Lock, internal width: 25mm, weight: 2075gr
Tires
Vittoria Barzo 29x2,25", Tubeless Ready, Graphene 2.0, 60 TPI, weight: 660gr
Brakes
Brakes
Shimano Deore XT BL-M8100
Cockpit
Handlebar
Avanforce AF3, Aluminum 6061, Ø31,8mm, width 740mm, weight 330gr
Seat
Saddle
Fizik Vento Argo X5, Steel rails 7x7mm, length 265 mm, width 140 mm, weight 240g
Seatpost
Crank Brothers HIGHLINE 3 Dropper post, Aluminum 7075-T6, 0 offset, Ø31,6, 125mm travel, weight: 545gr
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.356 mm | 1.314 mm | 1.266 mm |
| Bottom Bracket Height | 327 mm | 327 mm | 327 mm |
| Front Center | 717 mm | 739 mm | 765 mm |
| Rake | 46 mm | 46 mm | 46 mm |
| Trail | 112 mm | 108 mm | 104 mm |
| Stack | 590 mm | 602 mm | 614 mm |
| Reach | 435 mm | 458 mm | 485 mm |
| Seat Tube Angle | 76.2 ° | 76 ° | 75.8 ° |
| Seat Tube Length | 400 mm | 445 mm | 490 mm |
| Head Tube Angle | 67 ° | 67.5 ° | 68 ° |
| Head Tube Length | 85 mm | 95 mm | 105 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1143 mm | 1165 mm | 1191 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 47 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 169 cm | 180 cm |
| Rider Max Height | 171 cm | 185 cm | 195 cm |
