besv CT 2.1 2024
2024 E-bike
Estimate price |
4,071$
Weight | 29.6 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 50mm -
Fork Suntour NEX
-
Groupset Shimano -
Suspension Hardtail -
Motor Shimano 250W 85Nm mid-drive -
Battery 504WH -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
LG
173cm - 188cm
XL
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BESV CT 2-Series alloy frame, Shimano Steps and internal battery compatible
Suspension Fork
SR Suntour Nex-E25, Lockout, Coil damping, tapered alloy steerer, travel 50mm, QR-axle
Drivetrain
Shift Levers
Enviolo manual
Cassette
KMC for Enviolo, 18T
Crank
Samox for Shimano Steps, 38T chainring
Bottom Bracket
Shimano, integrated in motor
Chain
KMC E101 EPT
Pedals
Wellgo pedals with reflectors
Wheels
Rims
Formula CL-1420 front hub, Enviolo Trekking 380% gear ratio rear hub, 700c multichamber alloy rims 36H
Tires
47x622
Brakes
Brakes
Hydraulic disc brake, 2-piston, 180mm front and rear rotors
Brake Levers
2 finger hydraulic disc brake lever
Cockpit
Stem
3D Forged alloy City-Trekking stem, adjustable 0-90 degree, 31.8mm clamp
Handlebar
Alloy City-Trekking rise bar, 6066 alloy, 40mm rise, sweep: 20 degree up, 31.8mm clamp
Grips
Comfortable gel grips with padding
Headset
First, D346S, 1.5" headset, angular contact bearings
Seat
Saddle
Selle Royal Rio Moderate
Seatpost
Suspension seatpost with anty-sideplay, 40mm travel, 31.6mm diameter, 12mm offset
Motor & Battery
Motor
Shimano EP600 center-motor, 250W rated power, 85Nm of torque, 25km/h maximum assist
Battery
504WH
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | LG | XL |
|---|---|---|
| Stack Reach Ratio | 1.624 mm | 1.553 mm |
| Front Center | 680 mm | 694 mm |
| Rake | 45 mm | 44 mm |
| Trail | 82 mm | 80 mm |
| Stack | 661 mm | 663 mm |
| Reach | 407 mm | 427 mm |
| Top Tube Length | 610 mm | 630 mm |
| Seat Tube Angle | 73 ° | 73 ° |
| Seat Tube Length | 550 mm | 600 mm |
| Head Tube Angle | 69.5 ° | 70 ° |
| Head Tube Length | 190 mm | 190 mm |
| Chainstay Length | 485 mm | 485 mm |
| Wheelbase | 1158 mm | 1172 mm |
| Bottom Bracket Drop | 65 mm | 65 mm |
| Standover Height | 833 mm | 864 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 173 cm | 185 cm |
| Rider Max Height | 188 cm | 200 cm |
