Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset 105 Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Shimano 105 Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aero TT Disc ACR Carbon Monocoque
Suspension Fork
Aero TT, Integrated Tapered Full Carbon 1.5
Drivetrain
Rear Derailleur
Shimano 105 DI2 7150 12sp
Front Derailleur
Shimano 105 DI2 7150
Shift Levers
Shimano 105 DI2 Hydra
Cassette
Shimano 105 11/34
Crank
Shimano 105 FCR7100 52/36
Chain
Shimano 105
Wheels
Rims
Vision Team TC 30
Tires
Hutchinson Nitro2 700x 28
Brakes
Brakes
Front: Shimano 105 Hydraulic, Rear: Shimano 105 Hydraulic
Cockpit
Stem
Aero TT ACR
Handlebar
Vision Trimax Carbon ACR
Headset
Aero TT ACR
Seat
Saddle
BH Ergo G
Seatpost
BH Aero TT
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.208 mm | 1.212 mm | 1.225 mm | 1.235 mm |
| Bottom Bracket Height | 262 mm | 262 mm | 262 mm | 262 mm |
| Front Center | 589 mm | 602 mm | 619 mm | 638 mm |
| Rake | 53 mm | 53 mm | 54 mm | 53 mm |
| Trail | 50 mm | 49 mm | 47 mm | 49 mm |
| Stack | 494 mm | 509 mm | 528 mm | 547 mm |
| Reach | 409 mm | 420 mm | 431 mm | 443 mm |
| Top Tube Length | 531 mm | 547 mm | 562 mm | 579 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 510 mm | 525 mm | 540 mm | 560 mm |
| Head Tube Angle | 72.5 ° | 72.8 ° | 72.8 ° | 72.8 ° |
| Head Tube Length | 85 mm | 100 mm | 120 mm | 140 mm |
| Chainstay Length | 380 mm | 380 mm | 380 mm | 380 mm |
| Wheelbase | 970 mm | 983 mm | 1001 mm | 1018 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 74 mm | 74 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
