Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NX 1
-
Groupset Deore -
Suspension Hardtail -
Motor mid-drive -
Battery 720Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sport Hybrid Alloy 28" Internal Cable Routing
Suspension Fork
SR Suntour NX1 63mm
Drivetrain
Rear Derailleur
Shimano Deore 10sp
Front Derailleur
-
Shift Levers
Shimano Deore
Cassette
Shimano CSM4100 10sp (11-46T)
Crank
FSA 38T-170mm
Bottom Bracket
-
Chain
Shimano HG54
Pedals
Alloy
Wheels
Front Hub
Shimano
Rear Hub
Shimano
Rims
Alloy Double Wall
Spokes
Stainless Steel
Tires
Schwalbe Big Apple 28"x2,0
Brakes
Brakes
Front: Shimano MT200 180mm, Rear: Shimano MT200 180mm
Cockpit
Stem
BH Adjustable
Handlebar
BH Lite Riser 720mm
Grips
Ergon GP10
Headset
Acros AIF-544 ICR IPS
Seat
Saddle
Selle Royal Look In Basic Confort
Seatpost
Alloy 31,6
Motor & Battery
Motor
TS System
Battery
720Wh
