Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset GRX 800 -
Suspension Rigid -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Gravel X Alloy 7005 Hydroforming
Suspension Fork
Gravel X Carbon 1.5"
Drivetrain
Rear Derailleur
Shimano GRX 24sp
Front Derailleur
Shimano GRX
Shift Levers
Shimano GRX hydra
Cassette
Shimano 105 11/34
Crank
Shimano GRX 46/30
Chain
Shimano 105
Wheels
Rims
Vision Team TC30 Disc
Tires
Hutchinson Touareg Tan 700x40
Brakes
Brakes
Front: Shimano Disc hydra, Rear: Shimano Disc hydra
Cockpit
Stem
BH SL
Handlebar
BH Lite Gravel
Headset
BH SL integrated sealed bearing
Seat
Saddle
BH Ergo G
Seatpost
BH Lite 27,2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.393 mm | 1.459 mm | 1.475 mm | 1.491 mm | 1.503 mm |
| Bottom Bracket Height | 282 mm | 274 mm | 276 mm | 276 mm | 278 mm |
| Front Center | 584 mm | 591 mm | 602 mm | 614 mm | 626 mm |
| Rake | 45 mm | 52 mm | 53 mm | 53 mm | 52 mm |
| Trail | 82 mm | 68 mm | 64 mm | 61 mm | 59 mm |
| Stack | 510 mm | 540 mm | 556 mm | 577 mm | 598 mm |
| Reach | 366 mm | 370 mm | 377 mm | 387 mm | 398 mm |
| Top Tube Length | 503 mm | 527 mm | 548 mm | 567 mm | 587 mm |
| Seat Tube Angle | 75 ° | 73.75 ° | 73 ° | 72.75 ° | 72.5 ° |
| Seat Tube Length | 478 mm | 500 mm | 520 mm | 540 mm | 560 mm |
| Head Tube Angle | 69.5 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1000 mm | 1009 mm | 1019 mm | 1031 mm | 1044 mm |
| Bottom Bracket Drop | 67 mm | 75 mm | 73 mm | 73 mm | 71 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
