Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Gravel X Carbon Monocoque
Suspension Fork
Gravel X Evo Carbon 1.5"
Drivetrain
Rear Derailleur
Shimano GRX
Front Derailleur
Shimano GRX
Shift Levers
Shimano GRX hydra
Cassette
Shimano 105 11/34
Crank
FSA Gossamer 386 50x34
Bottom Bracket
386EVO, 86mm, press-fit
Chain
FSA TH-CN1102
Wheels
Rims
Shimano RS170 Disc
Tires
Hutchinson Overide 700x38
Brakes
Brakes
Front: Shimano GRX hydra, Rear: Shimano GRX hydra
Cockpit
Stem
BH SL
Handlebar
BH Lite Gravel
Headset
BH SL integrated sealed bearing
Seat
Saddle
Prologo Nago RS
Seatpost
BH Lite 27,2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Top Tube Length | 529 mm | 550 mm | 571 mm | 592 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm |
| Head Tube Angle | 69.5 ° | 71.1 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 100 mm | 125 mm | 150 mm | 180 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
