Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Factory Float 34
-
Groupset XT -
Suspension Full -
Motor mid-drive -
Battery 630Wh -
Drivetrain 1 × 12 -
Brakes Shimano XT Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
120 mm Full Suspension Carbon 29" ICR
Suspension Fork
FOX 34 FLOAT Factory SC 120mm 15QR
Rear Shock
FOX FLOAT DPS Performance
Drivetrain
Rear Derailleur
Shimano XT 12sp
Shift Levers
Shimano XT
Cassette
Shimano CSM8100 12sp (10-51T)
Crank
FSA 34T-165mm
Chain
Shimano CNM6100
Wheels
Front Hub
BH Evo
Rear Hub
BH Evo
Rims
BH Evo A30 Alu TR
Spokes
Stainless Steel
Tires
Maxxis Ardent /Ikon TPI120 MaxxSpeed EXO TR 29X2,2
Brakes
Brakes
Front: Shimano XT 4 Piston 180mm, Rear: Shimano XT 4 Piston 180mm
Cockpit
Stem
BH Evo 31 Fit
Handlebar
BH MTB SLite Alloy Riser 780mm
Grips
Ergon GE1-Factory
Headset
Acros AIF-560 ICR BL.
Seat
Saddle
Prologo Scratch M5 Stn
Seatpost
Bike Yoke Divine 31,6, X, Seatpost, Bike Yoke Divine 31,6, LA 80mm, MD 80mm, SM 80mm, XL 80mm
Motor & Battery
Motor
NR System
Battery
630Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.361 mm | 1.323 mm |
| Bottom Bracket Height | 342.5 mm | 342.5 mm | 342.5 mm |
| Front Center | 686 mm | 709 mm | 730 mm |
| Rake | 42 mm | 43 mm | 43 mm |
| Trail | 102 mm | 101 mm | 101 mm |
| Stack | 592 mm | 599 mm | 606 mm |
| Reach | 420 mm | 440 mm | 458 mm |
| Top Tube Length | 573 mm | 595 mm | 615 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 453 mm | 453 mm | 453 mm |
| Wheelbase | 1139 mm | 1162 mm | 1183 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm |
| Standover Height | 739 mm | 760 mm | 779 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
