Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Shimano Tiagra Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Quartz Disc Aluminium 6061, Thru Axle 12mm
Suspension Fork
Quartz Disc, Integrated Carbon 1.5"
Drivetrain
Rear Derailleur
Shimano Tiagra 10sp
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra
Cassette
Shimano Tiagra11/34
Crank
Shimano Tiagra 46/34, X, Crank set, Shimano Tiagra 46/34, LA 172,5mm, MD 170mm, SM 170mm, XL 172,5mm
Chain
FSA TH-CN90N
Wheels
Rims
Slite Thru Axle
Tires
Hutchinson Nitro2 700x28
Brakes
Brakes
Front: Shimano Tiagra mechanic, Rear: Shimano Tiagra mechanic
Cockpit
Stem
BH SL, X, Stem, BH SL, LA 100mm, MD 80mm, SM 80mm, XL 110mm
Handlebar
BH Lite Compact, X, Handlebar, BH Lite Compact, LA 440mm, MD 420mm, SM 420mm, XL 440mm
Headset
BH Lite 1.5"
Seat
Saddle
San Marco Monza Start
Seatpost
BH Lite 27,2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Top Tube Length | 530 mm | 543 mm | 557 mm | 570 mm | 583 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm |
| Head Tube Angle | 72.5 ° | 72.5 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 115 mm | 140 mm | 165 mm | 185 mm | 200 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
