Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Shimano 105 Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SL1 Disc ICR Monocoque
Suspension Fork
SL1 Disc Full Integrated Tapeder, Full Carbon 1.5´
Drivetrain
Rear Derailleur
Shimano 105 RD7100 12sp
Front Derailleur
Shimano 105 7100
Shift Levers
Shimano 105 Hydra
Cassette
Shimano 105 11/34
Crank
Shimano 105 FCR7100 52/36
Chain
Shimano 105
Wheels
Rims
Shimano RS171 Disc
Tires
Hutchinson Nitro 700x 28
Brakes
Brakes
Front: Shimano 105 Hydraulic, Rear: Shimano 105 Hydraulic
Cockpit
Stem
BH SL
Handlebar
BH Lite Compact
Headset
FSA ICR
Seat
Saddle
San Marco Monza Start
Seatpost
BH Lite 27,2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.353 mm | 1.366 mm | 1.43 mm | 1.51 mm | 1.5 mm |
| Bottom Bracket Height | 261 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 565 mm | 577 mm | 580 mm | 593 mm | 603 mm |
| Rake | 31 mm | 40 mm | 43 mm | 43 mm | 41 mm |
| Trail | 78 mm | 67 mm | 58 mm | 58 mm | 60 mm |
| Stack | 517 mm | 523 mm | 549 mm | 583 mm | 594 mm |
| Reach | 382 mm | 383 mm | 384 mm | 386 mm | 396 mm |
| Top Tube Length | 510 mm | 544 mm | 557 mm | 570 mm | 586 mm |
| Seat Tube Angle | 74.8 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 398 mm | 433 mm | 463 mm | 493 mm | 504 mm |
| Head Tube Angle | 71.8 ° | 72 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 108 mm | 120 mm | 150 mm | 185 mm | 196 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 963 mm | 978 mm | 981 mm | 994 mm | 1005 mm |
| Bottom Bracket Drop | 74 mm | 65 mm | 65 mm | 65 mm | 64 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
