Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tourney -
Suspension Rigid -
Brakes Shimano Alivio Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Spike 29", Alloy Frame
Suspension Fork
Spike
Drivetrain
Rear Derailleur
Shimano TX55 7sp
Front Derailleur
Shimano TY300
Shift Levers
Shimano ST-EF505
Cassette
Shimano HG-200
Crank
Prowheel
Bottom Bracket
Integrated
Chain
KMC
Pedals
Fasten
Wheels
Front Hub
Shimano TX505
Rear Hub
Shimano TX505
Rims
Alloy 29"
Tires
DSI
Brakes
Brakes
Front: Shimano MT-200, Rear: Shimano MT-200
Cockpit
Stem
BH Alloy
Handlebar
BH
Grips
BH
Headset
BH
Seat
Saddle
BH
Seatpost
BH
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 649 mm | 662 mm | 676 mm | 696 mm |
| Top Tube Length | 575 mm | 587 mm | 600 mm | 620 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 390 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1097 mm | 1110 mm | 1124 mm | 1144 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
