Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset GRX 800, GRX Di2 -
Suspension Rigid -
Drivetrain 1 × 11 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Arcadex Carbon, 1.5" headset, seatpost diam. 31.6mm, thru axle 12x142mm, flat mount caliper, Pressfit 41 BB, compatible with 42mm tire and mudguard predisposition, sizes: XS-SM-MD-LG-XL
Suspension Fork
Bianchi Full Carbon Disc, 1.5" head, flat mount caliper, thru axle 12x100mm
Drivetrain
Rear Derailleur
Shimano GRX RX 817 Di2, RD-RX817, 11sp, top normal shadow plus design, direct attachment
Shift Levers
Shimano GRX 815 Di2 11sp Hydraulic disc brake
Cassette
Shimano XT CS-M8000 11sp, 11-13-15-17-19-21-24-28-32-37-42T
Crank
Shimano GRX 810 FC-RX810-1 40T, Hollowtech II, Crank Length: 170mm-XS-SM, 172.5mm-MD-LG, 175mm-XL
Bottom Bracket
Shimano SM-BB72-41B
Chain
Shimano Ultegra CN-HG701-11
Wheels
Rims
Fulcrum Rapid Red 500 DB 2WF-R C23 AFS
Tires
WTB Riddler Race 700x37
Brakes
Brakes
Shimano BR-RX810
Brake Levers
included w/shifters
Cockpit
Stem
Reparto Corse by Fsa ST-OS-188/SMR-0°, Alloy 6061, 1 1/4", rise 0°, Ext: 80mm-XS/S, 100mm-M, 120mm-L/XL
Handlebar
Reparto Corse Aero shape, Aluminum 6061, reach 70mm, flare angle 16°, drop cc 130mm, size: 40cm-XS/S, 42cm-M/L, 44cm-XL
Grips
La Spirale Ribbon cork
Headset
FSA SMR HS with 1.1/8” custom top cone Bianchi, H2475, Internal Headset, Integrated Alloy custom top cup 1.1/8", 1.5", 36°/45° ACB
Seat
Saddle
Fi'zi:k Argo Tempo R5, nylon carbon reinforced shell w/WingFlex, rail S alloy, 260x150mm
Seatpost
Reparto Corse carbon shaft UD finish, forged alloy head, 15mm offset L350mm, 31,6mm, Length: 300mm-XS, 350mm-S/M/L/XL, FSA Sleeve Di2 31.6mm
