Bianchi Aria e-Road 105 2025
2025 E-bike
Estimate price |
4,827$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset 105 -
Suspension Rigid -
Motor MAHLE 250W hub-drive -
Battery Mahle X35+ 250Wh -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-Road Aria aero carbon, mechanical/electronic, BB-PressFit 86,5x41, head tube 1.4"-1.1/8", integrated seat clamp, full carbon dropout, aero shape DT-ST, Disc brake flat mount, QR sytem, OLD 135mm sizes 47-50-53-55-57-59-61cm
Suspension Fork
Full Carbon Aero Road 1.4">1.1/8" integrated head, Disc brake flat mount, thru axle 12x100
Drivetrain
Rear Derailleur
Shimano, 105
Front Derailleur
Shimano, 105
Shift Levers
Shimano DISC BRAKE SET, 105
Crank
Shimano, 105, 50-34T Crank Length: XS-S - 170mm M-L - 172.5mm XL - 175mm
Bottom Bracket
Shimano,SM-BB72-41B, PRESS FIT TYPE FOR ROAD, BEARING, INNER COVER
Chain
Shimano 105
Wheels
Rear Hub
FSA Vision Trimax alloy disc with rear Mahle motor hub
Rims
FSA Vision Trimax alloy disc with rear Mahle motor hub
Tires
Vittoria Rubino Pro G2.0 graphene, 700 x 28c, 150TPI
Brakes
Brakes
Shimano included in the shifter
Cockpit
Stem
Velomann, raise - 6°, height 38mm, Oversize, 1 1/8", size 90/100/110/120cm Ext: 90mm-48/50cm, 100mm-52/54cm, 110mm-56cm, 120mm-58cm
Handlebar
Velomann, Flat Top, alloy 6061 diam. 31,8mm, reach 80mm, drop 130mm Size: 400mm-44/53cm, 420mm-55/59cm, 440mm-61cm
Headset
FSA Orbit C-33, NO.44E, 1-1/8
Seat
Saddle
Velomann, carbon steel rail, 262x145
Seatpost
Full Carbon Aero special dimension, special Clamp type with alloy head adjustable and reversible +/- 35mm; lenght: 300mm - 47/50cm; 350mm - 53/61
Motor & Battery
Motor
Mahle X35 Plus 250W motor unit, iWOC One remote control, BLE and ANT+ compatible
Battery
Mahle X35+ 250Wh
