Bianchi E-OMNIA FX XT 2025
2025 E-bike
Estimate price |
5,350$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 160mm -
Travel Rear 150mm -
Fork Fox Rhythm Float 36
-
Groupset XT, Deore -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTube 625Wh integrated battery -
Drivetrain 1 × 12 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
e-OMNIA FX-Type ALU sizes: 43, 48, 53 - 12x148 mm thru axle dropouts (special dropout for external derailleur) - Post mount 180 disc brake type - 160/150mm travel front - 150mm travel rear
Suspension Fork
Fox 36 Float eBike optimized 29", Rhythm, 160mm travel, 1.5" tapered HT, QR 15x110mm BOOST axle, minimum 180mm rotor, maximum 230mm rotor, 44mm rake, 58mm crown
Rear Shock
FOX Float, Performance, 185/55, EVOL, 3 position lever, 0.3 Spacer, Neutral Decal
Drivetrain
Rear Derailleur
Shimano, RD-M8100, XT, SGS 12-SPEED
Shift Levers
Shimano, SL-M6100-IR, DEORE,12-SPEED
Crank
FSA CK-762/IS Forged Alu crank 165 mm ISIS Shimano CHAINRING, SM-CRE80-12, 34T
Bottom Bracket
included in the motor
Chain
Shimano, CN-M7100, 12sp
Wheels
Front Hub
Formula CL-811 for Center Lock, 32h, 15x110mm TA
Rear Hub
Formula CL-3248 for Center Lock, 32h, 12x148mm TA
Rims
Velomann E30 Tubeless Ready 29", 622x30, 32 hole
Tires
Front: Pirelli Scorpion E-MTB M 29x2.6 TLR, 60tpi Rear: Pirelli Scorpion E-MTB R 27.5x2.6 TLR, 60tpi
Brakes
Brakes
Shimano, BL-MT501, BR-MT520, 4 pistons
Cockpit
Stem
Velomann +/-0°, 1,1/8 x diam.35mm, 50mm
Handlebar
Velomann, width 780mm, diam.35mm, rise 18mm, backsweep 8°
Headset
FSA NO.55R/558 1.5"
Seat
Saddle
Velomann Gnd Full-fit Start Up, carbon steel rail, 262x145
Seatpost
Velomann, diam.31,6mm, internal remote cable routing, 120mm/150mm travel
Motor & Battery
Motor
Bosch Performance Line CX, 250W, 85Nm, Purion display
Battery
Bosch PowerTube 625Wh integrated battery
