Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 150mm -
Travel Rear 150mm -
Fork RockShox ZEB Select
-
Groupset GX Eagle -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Integrated battery 720Wh -
Drivetrain 1 × 12 -
Brakes Shimano Deore Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
e-SUV carbon sizes: 43, 48, 53 - 12x148 mm thru axle dropouts - Post mount 180 disc brake type - 160/150mm travel front - 150mm travel rear
Suspension Fork
RockShox ZEB Select 29", 150mm travel, 1.5" tapered HT, Maxle Stealth 15x110mm BOOST axle, minimum 200mm rotor, maximum 220mm rotor, 44mm rake, 63mm crown, DebonAri+, extl rebnd, 38mm stanchions
Rear Shock
RockShox Deluxe Select+, 185/55, DebonAir Linear, Damper Type RL, Compression tune M, Lockout Force 430, black finish tube, external rebound adjustment, Volume reducer 0 Neg 1 Pos
Drivetrain
Rear Derailleur
SRAM GX Eagle 12sp
Shift Levers
SRAM GX EAGLE 1x12
Crank
Shimano CRANK ARM SET, FC-EM600, 165MM, SRAM chainring XSYNC2 34T
Bottom Bracket
included in the motor
Chain
SRAM NX EAGLE, 12sp
Wheels
Front Hub
Formula CL-811 for Center Lock, 32h, 15x110mm TA
Rear Hub
Formula CL-1481, for Center Lock, 32h, 12x148mm TA
Rims
DT Swiss, H1900 Spline 27,5 rear" 35mm & 29 front 30mm, 15x110TA front, 12x148TA rear Shimano body, TL-ready rim w/eyelets
Tires
Rear: Scorpion E-MTB R 27.5x2.6 TLR, 60tpi
Brakes
Brakes
SHIMANO, BL-M6100, BR-M6120, 4 pistons
Cockpit
Stem
Velomann, 50mm, 35mm, 1"1/8
Handlebar
Velomann, width 780mm, diam.35mm, rise 18mm, backsweep 8°
Headset
FSA NO.55R/558 1.5"
Seat
Saddle
Fi'zi:k Alpaca Terra F207URN, S alloy rail, 249x145
Seatpost
Alpha1 Series - 31.6 mm - Remote RM07 I-Spec EV 125 mm - for size M 150 mm - for size L/XL
Motor & Battery
Motor
Shimano EP8, 250W, 85Nm
Battery
Integrated battery 720Wh
